Pump Study Bench

This bench enables the study of the operation and performance of centrifugal pumps, which are the fundamental actuators in process engineering across many fields. Learning Objectives: Study of a single pump. Determination of characteristic curves (suction and delivery). Learn about Pump Study Bench for educational labs for optimal educational outcomes.. Study of the flow/pressure relationship. Influence of suction head. Learn about Pump Study Bench exporters for optimal educational outcomes.. Influence of rotational speed on flow rate. Measurement of electrical power absorbed by a pump. Learn about Pump Study Bench specifications for optimal educational outcomes.. Measurement of mechanical power absorbed by a pump. Calculation of pump efficiency. Learn about Pump Study Bench India for optimal educational outcomes.. Demonstration of the cavitation phenomenon.

One launch tank with drain valve. One stainless-body centrifugal pump on anti-vibration mounts, torque-balanced for mechanical power measurement.

One launch tank with drain valve.
One stainless-body centrifugal pump mounted on anti-vibration mounts; the pump is mounted in a torque balance for mechanical power measurement.
One transparent PVC suction assembly with strainers and valves.
One delivery assembly in PVC with membrane-type control valves.
2 pressure measurements: one manovacuometer; one pressure gauge.
1 rotameter.
One integrated wattmeter with digital indicator.
One pump speed measurement with proximity detector and digital indicator.
One electronic frequency variable speed drive with control potentiometer.
One IP55 control cabinet with general switch with indicator light, fuses, mushroom-head emergency stop, start/stop button.
One support frame in 304L stainless steel tubing with aluminium fittings.
