Remote Control Application Via Telephone

The Remote Control Application Via Telephone, is designed to study the operation of a remote control system via telephone, in other words, for the remote control of sensors, alarms, etc.

ATENG 11075 — Remote Control Application Via Telephone

• The application “ATENG 11075” includes the following elements:
• N-ALI02. Domestic Main Power Supply Module.
• Supply voltage (single-phase): 230 VAC, 1PH + N.
  ON / OFF removable key.
• Output voltage connections:
• Two single-phase: 230 VAC.
  Single-shase supply hose connecting plug.
  N-ALI02
• Differential magnetothermal, 2 poles, 25 A, 30 mA AC, 6 KA.
  Emergency stop push-button.
• N-CTR01. Basic Control Module.
• Two voltage inputs, 230 VAC.
• Frequency: 50 Hz.
  Five inputs.
  Five outputs per relay (20 outputs).
  N-CTR01
  One telephone connection input.
  One telephone connection output.
• N-VAR05. Tone Dialing Telephone.
  Standard telephone with tones.
• All necessary cables to realize the practical exercises are included.
  Cables and accessories, for normal operation. N-VAR05
