Runnable APU Training Set

Trainees can learn the basic components and systems of a gas turbine engine with the Runnable APU Training Set. They can operate a gas turbine engine with the training set after learning the required operational procedures. The training set includes all the systems typically found on a gas turbine engine.

Manufactured by Atico Export with quality-focused production and attention to engineering specifications for teaching and training purposes.

Engine Specifications :

• Power Output: 50 BHP (Air delivery)
• RPM: 51,275 (100%), Idle 44,350 (86.5%)
• Compressor: Centrifugal Impeller
• Combustion Chamber: Reverse Flow
• Annular with 8 Burners
• Turbine: 2 Stage Axial Flow
• Layout: Single Spool with Reduction Gearbox
• Starting: Starter Motor with Integral Speed Sensor
• Ignition: HT Igniters with 2 Plugs
• Fuel System: Electric Motor Driven Gear Pump with Electronic Control System
• Lubrication: Dry Sump with Electric Driven Pump, Oil Specification MIL-L-7808
• Air Delivery: 0.415 Kg/Sec @ 45 PSI
• Application: Air Producer in Various Aircraft Applications

Documentation :

• User’s Manual
• Study Guide

Power Specs :

• Electrical box
• Residual current device
• Emergency button
• Energy signal lamp
• 110 VAC 60 Hz or 220-240 VAC 50 Hz

• Delivered ready for build-up and runnable applications
• Instrument panel (Analog or Digital)
• Fuel-system components / fuel pump
• Oil tank
• Fuel tank
• Ignition harness
• Starter
• Electrical system
• Engine-to-instrument console, with umbilical cord for safety
• Mounted on easy-to-roll work stands
