Sieve Shaker - 400mm

Our Sieve Shaker is a reliable solution that provides high performance in sample preparation and sieving processes in the laboratory environment. The device is suitable for both dry and wet sieving processes and can sieve a wide range of particle sizes. Its user-friendly features and adjustable shaking speed, it offers flexible working opportunities with different samples.

Working Principle :
Sieve Shaker is a sample preparation device that allows materials to be separated into certain size ranges. The device works with the help of °400 mm sieves placed inside. The process takes place with these steps:

• Sample Preparation : The sample is poured onto the top of the sieves arranged on top of each other placed inside the device. Each of the sieves has a certain mesh size and the material is classified according to this mesh size.

• Shaking Motion : The device produces a shaking motion to pass the sample through the sieves. This movement allows the materials inside the sieves to pass through the sieve eyes. During the sifting process, the device makes an infinitely adjustable shaking movement at a speed of 0-300 rpm.

• Separation of Particles : The sample poured from the top is sieved in layers depending on the mesh sizes of the sieves. While the larger pieces remain in the upper sieves, the smaller pieces pass through the smaller sieves and are collected in the bottom layer.

• Collecting the Results : After the sieving process is completed, each of the sieves is removed one by one and the materials collected in each sieve are analyzed. The lower collection container collects the smallest sizes of materials.

Fields of Application :

• ISO 17827-1, Mining, Metallurgy, Recycling and Waste Recovery, Geology, Chemistry, Plastic and Polymer, Iron and Steel, Energy, Biotechnology, Environmental Management, Construction and Structure, Agriculture, Glass and Ceramics, Food, Geology, Pharmaceuticals and Medical

Application :

• Elimination, Separation

Timer Setting :

• Digital timer

Sieving Motion (Circular) :

• Horizontal circular motion

Sieve Dimensions :

• ° 400 mm

Speed :

• Infinitely adjustable between 0–300 rpm

Power and Electricity :

• 0.37 kW, 220 V, 1p, 50 Hz

Multiple Sieve Capacity :

• The shaker accommodates stacking up to eight standard test sieves, each with a diameter of °400 mm, for simultaneous use.

Suitable for Dry and Wet Sieving :

• Compatible with both dry and wet sieving processes, adapting to various sample preparation needs in the laboratory.

Wide Sieving Range :

• Operates with sieves from 20 °m to 20 mm mesh size, allowing efficient separation across diverse particle sizes.

Sieve Accessories :

• Includes a bottom collecting pan and a top cover suitable for both dry and wet sieving applications as standard.
