Tension Specimen

The specimen is instrumented with strain gauges to characterize tensile deformations generated by the tension-flexion test bench. A 6-channel strain gauge bridge displays the deformation values.

Pedagogical Objectives:

• Evidence of small deformations
• Verification of longitudinal and transverse stress distribution at various points
• Determination of the longitudinal elastic modulus of the material (aluminium alloy)
• Determination of Poisson's ratio

Evidence of small deformations
Verification of longitudinal and transverse stress distribution at various points
Determination of the longitudinal elastic modulus of the material (aluminium alloy)
Determination of Poisson's ratio
