Three-Phase Transformer Construction Unit

The Three-Phase Transformer Construction Unit, for theoretical and practical training in the field of three-phase transformers. This unit offers several levels of training that will provide the user with essential knowledge and skills on the fundamental principles of three-phase transformer construction and commissioning.

ATENG 11113 — Three-Phase Transformer Construction Unit

• The “ATENG 11113” unit includes the following elements:
• TPT01. Three Phase Transformer 01.
  Iron transformer core structure.
  Winding columns.
  Front upper support with screw terminals.
• Dimensions: 150 x 150 x 30 mm (approx.)
  TPT01
• CHER. Tool Box.
  Tin.
  Tape measure.
  Insulating tape.
  Heat shrink tubing.
  Tension tester screwdriver.

CHER

Phillips and flat screwdrivers.

Allen wrenches.

Soldering iron and soldering iron stand.

Rubber hammer.

Connection terminals.

Cable ties.

Wire cutter.

Screw terminal.

• Required elements (Not included):
• N-VPS01. 3PH AC Power Supply Module.
  Removable ON/OFF key.
• Input voltage: 400 VAC, three phases and neutral.
  Emergency stop push button
  Adjustable three-phase thermal protection.
• 4-pole differential circuit breaker, 25 A, 300 mA AC 6 KA.
  N-VPS01
• Fuses 3 x 6 A.
• Motorized variable autotransformer:
• Rated power: 3000 VA.
• Input voltage: 400 VAC.
• Fixed output voltage:
• 3 x 400 VAC+N.
• Variable output voltage:
• 0 – 450 VAC (3PH+N).
• 0 – 240 VDC.
• 3-position switch with automatic return:
• Position I: voltage reduction.
• Position 0: constant voltage.
• Position II: voltage increase
• DC ammeter: 0 - 5 A.
• AC ammeter: 0 - 5 A.
• DC voltmeter: 0 - 300 V.
• AC voltmeter: 0 - 500 V.
• Rated current: 2 A.
• Frequency: 50/60 Hz.
• Three-phase power cable with IP44 3PN + E 32A 400 V plug.
  3

Specifications

• MWMT. Manual Winding Machine for Motors and Transformers.
  Mechanical handwheel.
  Turn counter.
  Winding molds.
  Rods to place the winding molds
  Winding parts of the transformer.
  Allen keys. MWMT
  Rod to place smaller coils
• MED65. Digital Multimeter.
• Digital multimeter with 3 ½ digits, with 4 mm double connector termination cables to facilitate
  interconnections.
• With this digital multimeter we can measure:
  Voltage.
  Current.
  Resistance.
  MED65
  Capacitors capacity.
  Temperature.
• Coils of copper wire of outside diameter 1.12 mm, 17 AWG.
• Coils of copper wire of outside diameter 1.08 mm, 18 AWG.
• All necessary cables to realize the practical exercises are included.
  Cables and accessories, for normal operation.
