Tripod Joint Case

Cases of tripod joints to study their characteristics and mechanical specificities. Educational Objectives: Kinematic study of the tripod joint, demonstration of joint homogeneity, justification of the assembly, geometric and kinematic analysis of the performance of an articulated mechanical joint.

Composition

• One disassembled tripod for mechanism analysis
• Two tripods for studying transmission characteristics with single or double joint
• CD-ROM: tripod joint study (EX518-10)
• CD-ROM with educational and technical resources (3D models)

One disassembled tripod for mechanism analysis
Two tripods for studying transmission characteristics with single or double joint
CD-ROM: tripod joint study (EX518-10)
CD-ROM with educational and technical resources (3D models)
