Wiring Installation Training for Entryphones

The application of Wiring Installation Training for Entryphones, for the students formation at a proffessional-practical level in the field of the installation, wiring and testing of entryphones electrical installations.

ATENG 11225 — Wiring Installation Training for Entryphones

• The “ATENG 11225” application includes the following elements:
• FP-STR. Assembly Frame with Safe Electrical Power Supply.
• Aluminum frame:
  Two aluminum struts.
  Easy assembly of components via hammer head screws.
  Possibility of simultaneous work of several students.
  Four swiveling casters to facilitate the movement.
• Dimensions:
• Frame height: 1800 mm.
• Useful working height: 1000 mm.
• Width: 1500 mm.
  Three-phase connection plug.
• Safe electric box:
• Differential magnetothermal, 4 poles, 25 A, 30 mA AC 6 KA.
• Emergency stop mushroom (230/400 VAC).
  5-wire hose for connection to frame.
  Signal lamp of voltage presence.
• FP-KIT-4. Wiring Installation Kit.
• 100 meters of grey wire of 1.5 mm².
• 100 meters of brown wire of 1.5 mm².
• 100 meters of black wire of 1.5 mm².
• 100 meters of green/yellow wire of de 1.5 mm².
  25 meters of screened wire.
• FP-KIT-10. Tubes and Fittings for Channeling Wiring Kit.
  20 metres of PVC pipe for wiring installation.
  Seven registry boxes.
  Wiring guide.
• 20 clamps for cable 20 mm.
• FP-KIT-69. Digital Entryphone Kit.
  2 x digital intercom.
  Keypad call.
  Electric lock.
  Power supply for the entryphone.
• FP-KIT-71. Bells Kit.
• Bell 230 VAC.
• Buzzer 230 VAC.
  2 x push-button switch.
  3

Specifications

• Required elements:
• CHER. Tool Box.
  Crimper.
  Tin.
  Meter.
  Insulation tape.
  Heat shrink.
  Hole finders.
  Crosshead screwdriver star and flat.
  Allen keys.
  Soldering iron and support for soldering iron.
  Rubber hammer.
  Connection terminals.
  Flanges.
  Wire cutter.
  Clamps.
  Wire stripper.
• Recommended elements:
• MED65. Digital Multimeter.
• This module has a digital multimeter of about 3 ½ digits, with double-jack ending cables of about 4 mm to facilitate interconnections.
• With this digital multimeter we will be able to measure:
  Voltage.
  Current.
  Resistance.
  Capacitors capacity.
  Temperature.
• FP-KIT-5. Measuring Kit.
• Clamp ammeters:
  Clamp for alternating/direct current measurements contactless.
• The clamp can measure:
  Current.
  Voltage.
  Resistance.
• A tester for voltage and continuity:
• Voltage range: 12 - 690 VAC.
  Phases rotating detection in three-phase systems.
  Polarity tester.
• FP-KIT-10/B. Rigid Tube Kit.
  20 m of PVC rigid tube.
  10 x threaded connector.
  5 x elbows for conducts clamping.
  5 x sealing plug.
• All necessary cables to realize the practical exercises are included.
  Cables and Accessories, for normal operation.
