Wiring Installation Training for Industrial Signalling Elements

The Wiring Installation Training, Industrial Signalling Elements application, for the formation at professional-practical level in the field of the installations, wiring and testing of the signaling application present in industry.

ATENG 11219 — Wiring Installation Training for Industrial Signalling Elements

• The “ATENG 11219” application includes the following elements:
• FP-STR. Assembly Frame with Safe Electrical Power Supply.
• Aluminium structure:
  Two aluminium struts.
  Easy assembly of components via hammer head screws.
  Possibility of simultaneous work of several students.
  Four swivelling casters to facilitate the movement.
• Dimensions:
• Structure heigh: 1800 mm.
  FP-STR
• Useful working height: 1000 mm.
• Width: 1500 mm.
  Three-phase connection plug.
• Safe electric box:
• Differential magnetothermal, 4 poles, 25 A, 300 mA AC 6 KA.
• Emergency stop mushroom (230/400 VAC).
  5-wire hose for connection to frame.
  Signal lamp of voltage presence.
• FP-KIT-4. Wiring Installation Kit.
• 100 m of grey wire of 1.5 mm².
• 100 m of brown wire of 1.5 mm².
• 100 m of black wire of 1.5 mm².
• 100 m of green/yellow wire of de 1.5 mm².
  25 m of screened wire.
  FP-KIT-4
• FP-KIT-10. Tubes and Fittings for Channelling Wiring Kit.
  20 m of PVC pipe for wiring installation.
  7 x Electrical box.
  Cable guide.
• 20 x Cable clamps, 20 mm.
  FP-KIT-10
• FP-KIT-32. Switches Kit 1.
  Two switches.
  Two double switches.
  Two commutators.
  One push-button.
• FP-KIT-44. Acoustic Signalling Kit.
• Ringer:
  FP-KIT-32
• Nominal voltage: 24 VAC.
• Buzzer:
• Nominal voltage: 24 VAC.
• FP-KIT-45. Lighting Signalling Kit.
• Three signaling lights:
• Colours: green, yellow and red.
  Two blinking lights.
• FP-KIT-46. Signalling Relay Kit.
• Two bistable relays:
• Coil voltage: 24 VAC.
• Two auxiliary relays:
• Coil voltage: 24 VAC.
  3

Specifications

• Required elements (Not included):
• CHER. Tool Box.
  Crimper.
  Tin.
  Meter.
  Insulating tape.
  Heat shrink.
  Pin punch.
  Star and flat screwdrivers. CHER
  Allen keys.
  Soldering iron and soldering iron support.
  Rubber hammer.
  Connection terminals.
  Cable ties.
  Cable cutters.
  Clamps.
