Wiring Installation Training for Network Systems

The Wiring Installation Training for Network Systems application, for the formation at professional-practical level in the field of the installations, wiring and testing of the technology employed in the network connection.

ATENG 11242 — Wiring Installation Training for Network Systems

• The “ATENG 11242” application includes the following elements:
• CHER. Tool Box.
  Crimper.
  Tin.
  Meter.
  Insulating tape.
  Heat shrink.
  Pin punch.

CHER

Star and flat screwdrivers.

Allen keys.

Soldering iron and soldering iron support.

Rubber hammer.

Connection terminals.

Cable ties.

Cable cutters.

Clamps.

• MED65. Digital Multimeter.
  This module has a digital multimeter of about 3 ½ digits, with double-jack ending cables of about
• 4 mm to facilitate interconnections.
• With this digital multimeter we will be able to measure:
  Voltage.
  Current.
  MED65
  Resistance.
  Capacitors capacity.
  Temperature.
• PAP. Perforated Aluminum Panel.
  Perforated aluminum sheet panel.
• Approx size: (width x high) 1200 x 800 mm.
  It is mounted in a structure to be placed in a workbench.
• WMPP. Wall-Mount Patch Panel.
  It allows to quickly change the port assignment of any equip connected to the network.
• Port types: RJ45.
• Number of ports: 12.
• Wire type: UTP wire.
• Wire category: 5e.
• SHCM. Self Healing Cutting Mat.
  Help to preserve the work surface and the life of knife blades.
• Dimensions:
• Height: 200 mm.
• Width: 300 mm.
• Thickness: 3 mm.
• FP-KIT-57. Wall Installation Kit.
  Wall assembly box.
  Push-on frame.
  Connector cover.
  Trim.
  3

Specifications

• FP-KIT-56. Network Wiring Kit.
• 100 meters of data wire:
  Unshielded twisted pair wire (UTP).
• Category: 5e.
• Pins: 8.
• Punchdown tool:
  Tool for a simple placement of the wires in the terminal blocks.
• Category of suitable wire: 5e, 6.
• Data cable stripper:
• Wire diameter: 3 – 11 mm.
• Category of suitable wire: 4, 5, 5e, 6, 7.
  Completely closed knife blade for total security.
• Data wire crimptool:
  Cut and peeled of UTP wire.
• Suitable connectors:
  6-poles type RJ11/12.
  8-poles type RJ45.
• Data wire tester:
  RJ45 male connector.
• Suitable to detect:
  Open circuits.
  Short-circuits.
  RJ45 male connectors.
  RJ45 female connectors.
• FP-KIT-5. Measuring Kit.
• Clamp meter:
  Clamp for alternating/direct current measurements contactless.
• The clamp can measure:
  Current.
  Voltage.
  FP-KIT-5
  Resistance.
• A voltage and continuity tester:
• Voltage range: 12 – 690 VAC.
  Phases rotating detection in three-phase systems.
  Polarity tester.
• All necessary cables to realize the practical exercises are included.
  Cables and accessories, for normal operation.
