Wiring Installation Training for Photovoltaic Systems

The Wiring Installation Training for Photovoltaic Systems, for the training at professional practical level in the field of the installations, wiring and commissioning of photovoltaic solar energy systems.

ATENG 11239 — Wiring Installation Training for Photovoltaic Systems

• The “ATENG 11239” application includes the following elements:
• MED65. Digital Multimeter.
  This module has a digital multimeter of about 3 ½ digits, with double-jack ending cables of
• about 4 mm to facilitate interconnections.
• With this digital multimeter we will be able to measure:
  Voltage.
  Current.
  Resistance.
  MED65
  Capacitors capacity.
  Temperature.
• FP-KIT-19. Lighting Consumption Kit.
• Two 12 VDC lamps.
• Two 230 VAC (PH + N) halogen bulb.
  Four switches.
• FP-KIT-18. On-Grid Photovoltaic Installation Kit.
• Micro inverter DC to AC:
• Nominal power: 350 W. FP-KIT-19
• Input voltage range: 18 – 60 VDC.
• Output voltage range: 184 – 264 VAC.
• FP-KIT-17. Stand-Alone Photovoltaic Installation Kit.
• Sine-wave inverter:
• Nominal power: 375 VA.
• Input voltage: 12 VDC.
• Output voltage range: 210 – 245 VAC.
• Electronic battery regulator:
• Possibility of connection to 12 or 24 VDC.
  LEDs to indicate the state of charge of the battery.
• Protection against:
  Overcurrent.
  Short-circuits.
  Reversal connection of solar panels or batteries.
• Battery:
• Battery voltage: 12 V.
• Battery capacity: 70 Ah.
• FP-KIT-16. Photovoltaic Generation Kit.
• Three lamps panel to simulate solar radiation:
• Power: 3 x 250 W.
  Switch ON / OFF.
  Intensity Regulator.
  Aluminum frame.
• 96 W Photovoltaic Panel:
• Maximum Power: 96 W.
• Voltage at maximum power: 17.8 V. FP-KIT-16
• FP-KIT-5. Measuring Kit.
• Clamp meter:
  Clamp for alternating/direct current measurements contactless.
• The clamp can measure:
  Current.
  Voltage.
  Resistance. FP-KIT-5
• A voltage and continuity tester:
• Voltage range: 12 – 690 VAC.
  Phases rotating detection in three-phase systems.
  Polarity tester.
• FP-KIT-4. Wiring Installation Kit.
• 100 m of grey wire of 1.5 mm².
• 100 m of brown wire of 1.5 mm².
• 100 m of black wire of 1.5 mm².
• 100 m of green/yellow wire of de 1.5 mm².
  25 m of screened wire. FP-KIT-4
  3

Specifications

• FP-KIT-1. Feeders Installation Kit.
• Differential magnetothermal, 4 poles, 25 A, 300 mA AC 6 KA.
• Single-phase fuse holder for DIN rail mounting:
• Fuse: 1 x 30 A.
• Three-phase fuse holder for DIN rail mounting:
• Fuses: 3 x 30 A.
  FP-KIT-1
• FP-STR. Assembly Frame with Safe Electrical Power Supply.
• Aluminium structure:
  Two aluminium struts.
  Easy assembly of components via hammer head screws.
  Possibility of simultaneous work of several students.
  Four swivelling casters to facilitate the movement.
• Dimensions:
• Structure heigh: 1800 mm.
• Useful working height: 1000 mm.
• Width: 1500 mm.
  Three-phase connection plug.
  FP-STR
• Safe electric box:
• Differential magnetothermal, 4 poles, 25 A, 300 mA AC 6 kA.
• Emergency stop mushroom (230/400 VAC).
  5-wire hose for connection to frame.
  Signal lamp of voltage presence.
• CHER. Tool Box.
  Crimper.
  Tin.
  Meter.
  Insulating tape.
  Heat shrink.
  Pin punch.
  Star and flat screwdrivers.
  Allen keys.
  Soldering iron and soldering iron support. CHER
  Rubber hammer.
  Connection terminals.
  Cable ties.
  Cable cutters.
  Clamps.
• All necessary cables to realize the practical exercises are included.
  Cables and accessories, for normal operation.
