Wiring Installation Training for Power Factor Correction Devices

The Wiring Installation Training, Power Factor Correction Devices application, for the formation at professional-practical level in the field of the installations, wiring and testing of existing power factor correction systems in industry.

ATENG 11221 — Wiring Installation Training for Power Factor Correction Devices

• The “ATENG 11221” application includes the following elements:
• FP-STR. Assembly Frame with Safe Electrical Power Supply.
• Aluminium structure:
  Two aluminium struts.
  Easy assembly of components via hammer head screws.
  Possibility of simultaneous work of several students.
  Four swivelling casters to facilitate the movement.
• Dimensions:
  FP-STR
• Structure heigh: 1800 mm.
• Useful working height: 1000 mm.
• Width: 1500 mm.
  Three-phase connection plug.
• Safe electric box:
• Differential magnetothermal, 4 poles, 25 A, 300 mA AC 6 kA.
• Emergency stop mushroom (230/400 VAC).
  5-wire hose for connection to frame.
  Signal lamp of voltage presence.
• FP-KIT-4. Wiring Installation Kit.
• 100 m of grey wire of 1.5 mm².
• 100 m of brown wire of 1.5 mm².
  FP-KIT-4
• 100 m of black wire of 1.5 mm².
• 100 m of green/yellow wire of de 1.5 mm².
  25 m of screened wire.
• FP-KIT-10. Tubes and Fittings for Channelling Wiring Kit.
  20 m of PVC pipe for wiring installation.
  7 x Electrical box.
  FP-KIT-9
  Cable guide.
• 20 x Cable clamps, 20 mm.
• FP-KIT-10/B. Rigid Tube Kit.
  20 m PVC rigid tube.
  10 x Threaded connector.
  FP-KIT-10
  5 x Elbow for conducts clamping.
• FP-KIT-48. Three-Phase Variable Loads Kit.
• Three-phase variable resistor:
• Nominal power: 2100 VA.
• Resistor range: 0 – 233 Ohm.
• Three-phase variable reactance:
• Nominal power: 2100 Var.
• Inductance: 742 mH.
• Reactance range: 0 – 233 Ohm.
  Two potentiometer to regulate the power load.
  3

Specifications

• FP-KIT-49. Stepper Power Factor Correction Kit.
• Capacitors battery:
• Nominal voltage: 400 VAC.
• Star connection nominal power: 2100 Var.
• Delta connection nominal power: 6300 Var.
  Capacitor discharge resistor.
• Power factor controller:
• Nominal voltage: 400 VAC.
  6 control steps.
  It shows the power factor of the system.
• Five three-pole contactors:
• Nominal voltage for power contacts: 400 VAC.
• Nominal voltage for control contacts: 230 VAC.
• Nominal voltage for the control coil: 230 VAC.
• Auxiliary contacts:
  3 NO / 2 NC.
  Harmonic filtered reactance.
• 6 x Single-phase fuse holders for DIN rail mounting:
• Fuse: 1 x 30 A.
• 6 x Three-phase fuse holders for DIN rail mounting:
• Fuses: 3 x 30 A.
• MED65. Digital Multimeter.
  This module has a digital multimeter of about 3 ½ digits, with double-jack ending cables of about
• 4 mm to facilitate interconnections.
• With this digital multimeter we will be able to measure:
  Voltage.
  Current.
  Resistance.
  MED65
  Capacitors capacity.
  Temperature.
• Required elements (Not included):
• CHER. Tool Box.
  Crimper.
  Tin.
  Meter.
  Insulating tape.
  Heat shrink.
  Pin punch.
  Star and flat screwdrivers.
  Allen keys. CHER
  Soldering iron and soldering iron support.
  Rubber hammer.
  Connection terminals.
  Cable ties.
  Cable cutters.
  Clamps.
