Wiring Installation Training for Start-up of DC and AC Motor Drives

The Wiring Installation Training, Start-up of DC and AC Motor Drives, for the formation at professional-practical level in the field of electrical motors controllers.

ATENG 11237 — Wiring Installation Training for Start-up of DC and AC Motor Drives

• The “ATENG 11237” application includes the following elements:
• FP-STR. Assembly Frame with Safe Electrical Power Supply.
• Aluminum structure:
  Three alminum struts.
  Easy assembly of components via hammer head screws.
  Possibility of simultaneous work of several students.
  Four swivelling casters to facilitate the movement.
• Dimensions:
• Structure height: 1800 mm.
• Workineight: 1000 mm. FP-STR
• Width: 1500 mm.
  Three-Phase connection plug.
• Safe electric box:
• Differential magnetothermal, 4 poles, 25A, 300mA AC 6KA.
• Emergency stop mushroom (230/400 VAC):
  5-wire hose for connection to frame.
  Signal lamp of voltage presence.
• FP-KIT-4. Wiring Installation Kit.
• 100 meters of grey wire of 1.5 mm².
• 100 meters of brown wire of 1.5 mm².
• 100 meters of black wire of 1.5 mm².
• 100 meters of green/yellow wire of de 1.5 mm².
  25 meters of screened wire.
  FP-KIT-4
• FP-KIT-10. Tubes and Fittings for Channeling Wiring Kit.
  PVC electrical conduit for wiring installation, 5 m.
  3 electrical boxes.
  Cable guide.
• CHER. Tool Box.
  FP-KIT-10
  Crimper.
  Tin.
  Meter.
  Insulation tape.
  Heat shrink.
  Pole finder.
  Voltage tester screwdriver.
  Cross-head screwdriver and flat-head screwdriver.
  Allen keys.
  Soldering iron and soldering iron support. CHER
  Rubber hammer.
  Wire terminals and connection terminals.
  Flanges.
  Wire cutter.
  Screw clamp terminals.
• MED65. Digital Multimeter.
• This digital multimeter of about 3 ½ digits, with double-jack ending cables of about 4 mm to
  facilitate interconnections.
• With this digital multimeter we will be able to measure:
  Voltage.
  Current.
  MED65
  Resistance.
  Capacitors capacity.
  Temperature.
  3

Specificacions

• FP-KIT-5. Measuring Kit.
• Clamp Meter:
  Clamp for alternating current measurements contactless.
• The clamp can measure:
  Current.
  Voltage.
  FP-KIT-5
  Resistance.
• A voltage and continuity tester:
• Voltage range: 12-690 VAC.
  Phases rotating detection in three-phase systems.
  Polarity tester.
• FP-KIT-6. Signaling and Control Kit.
• Three commutators:
  Two positions commutator.
• Three signalling lamps:
• Nominal voltage: 230 VAC.
  FP-KIT-6
  Three lamps (red, yellow and green).
• Emergency stop mushroom (230/400 VAC):
• Supply voltage: 230/400 VAC.
• EMT5-E. D.C. Shunt-series Compound Excitation Motor.
• Nominal power: 300 W.
• Armature voltage: 200 VDC.
• Excitation voltage: 230 VDC.
• Armature current: 1.5 A.
• Excitation current: 0.4 A.
  EMT5-E
• Speed: 3400/7500 rpm.
• Shaft height: 71 mm.
• FP-KIT-2. DC Motor Controller Installation Kit.
• DC Motor Controller:
• Supply voltage: 230 VAC (PH+N+G).
• Three ON/OFF switches:
  ON/OFF power switch.
  Star-Stop control activation switch.
  Internal tacho dynamo feedback switch.
• Two potentiometers:
  Speed control.
  Torque control.
• Terminals:
  Rotor terminals.
  Excitation terminals. FP-KIT-2
  Tacho dynamo terminals.
• Three driver status leds: (red, yellow and green).
• Variable output voltage: 0 - 300 VCC.
• A control cabinet with door:
• Dimensions:
• Height: 500 mm.
• Width: 400 mm.
• Depth: 200 mm.
  Cut rail, 2 m.
  Grey cable duct for wiring, 2 m.
  200 W, DC Motor with Wound Rotor.
  4

Specificacions

• -E. Asychronous Three-phase Motor of Squirrel Cage.
• Nominal power: 370 W.
• Nominal voltage: 3x 230/400 VAC Δ/Y
• Frequency: 50/60 Hz.
• Poles number: 2.
• Speed 2730 rpm.
  EMT7-E
• Shaft height: 71 mm.
• FP-KIT-3. AC Motor Controller Installation Kit.
• Frequency controller:
• Supply voltage: 230 VAC.
• Nominal power: 0,4 kW.
• PWM output voltage connections:
• Three-Phases: 230 VAC.
  Potentiometer for the induction motor control speed.
  Setting and visualization display of the machine parameters.
  FP-KIT-3
  EMC/EMI filter to limit electromagnetic interference.
  Speed control potentiometer.
• Control cabinet with door:
• Dimensions:
• Height: 500 mm.
• Width: 400 mm.
• Depth: 200 mm.
• FP-KIT-7. Manual starters kit for Three-Phase Induction Motor of Squirrel Cage.
• Manual Star-Delta starter:
• Nominal voltage: 400 VAC.
• Maximum current contacts: 10 A.
• Star-Delta three position commutator:
• 0: Open circuit.
  FP-KIT-7
• Y: star connection.
• Δ: delta connection.
• Direct manual starter:
• Nominal Voltage: 400 VAC.
• Maximum current contacts: 10 A.
• Two positions commutator (ON/OFF):
• 0: Open.
• 1: Close.
• Manual direct starter with inversión:
• Nominal voltage: 400 VAC.
• Maximum current contacts: 10 A.
• Three positions commutator:
• 0: Open.
• 1: Direct connection.
• 2: Inverse connection.
• TRANS03. Three-phase Autotransformer 400/230 VAC.
  Three-Phase autotransformer.
• Supply voltage: 400 VAC (3PH).
• Nominal output voltage: 3 x 230 VAC (3PH + N).
• Nominal power: 1 kVA.
• Transformer connection: YY0.
  TRANS03
  Start / stop switch for instantaneous connection / disconnection of the network transformer.
• Fuses: 3 x 5 A.
  GND terminal.
  5

Specificacions
