Automatic Cleveland Open Cup Flash Point Tester for Petroleum Testing Equipment

The Automatic Cleveland Open Cup Flash Point Analyzer is designed for determining the flash and fire points of petroleum products, excluding fuel oils, with flash points above 79°C and below 400°C. It features an integrated processor, a 10.4-inch touchscreen interface, automatic barometric pressure correction, and a dual fan cooling system for efficient testing. Test results can be stored on the local hard drive for convenient data management. The system supports gas or electric ignition and includes an automatic fire suppression system for enhanced operational safety.

Manufactured by Atico Export with a focus on precision, durability and consistent performance in petroleum testing laboratories.

• Determination of flash and fire points of petroleum products
• Testing of lubricants and petroleum-based materials
• Quality control and evaluation in petroleum laboratories
• Research and industrial petroleum testing applications

Temperature Measuring Range :

• Ambient temperature to 405°C (761°F)

Ignition Source :

• Gas or electric igniter, software selectable

Flash Detection System :

• Ionization detection

Cooling System :

• Integrated dual fan system

Barometric Pressure Correction :

• Automatic correction using an integrated barometric pressure transducer

Display :

• 10.4-inch LCD touchscreen

Test Cup :

• Included

Igniter Assembly :

• Included

Flash Point Software :

• Integrated

Dimensions in Closed Test Position :

• 34.6 × 54.6 × 41.6 cm

Dimensions in Fully Open Test Position :

• 34.6 × 54.6 × 52.7 cm

Net Weight :

• 22.7 kg

Clarify the temperature range wordingSeparate applications from testing uses

• Conforms to ASTM D92 and related specifications
• Simple automated operating routine
• Suitable for samples with open-cup flash points above 79°C
• Integrated fire suppression system using inert gas
• Equipped with an emergency safety switch
• Automatic barometric pressure correction
• Integrated dual fan system for cooling the test cup and surrounding environment
• Software-selectable gas or electric ignition
• Integrated processor with Windows-based operating software
• 10.4-inch LCD touchscreen displaying operating parameters and test results
• Local hard drive for storing test data
• Ionization-based flash detection system
