Automatic Density Meter for Petroleum Testing Equipment

The Automatic Density Meter is designed to determine the density and relative density of crude oils, petroleum distillates, viscous oils and other petroleum products that remain liquid at test temperatures between 15°C and 35°C. It supports accurate petroleum analysis and quality control through advanced measurement technology, multiple operating modes and a user-friendly touchscreen interface. The system offers horizontal loading, vertical loading and assisted sample loading options to suit different laboratory requirements. It also features video-assisted cell viewing, data storage and multiple communication interfaces for convenient operation and data management.

Manufactured by Atico Export with a focus on precision, durability and consistent performance in petroleum testing laboratories.

• Density and relative density determination of crude oils
• Testing of petroleum distillates and viscous oils
• Quality control of petroleum products and fuels
• Petroleum research and industrial laboratory analysis
• Density measurement of liquid samples

Measurement Ranges :

Density :

• 0 to 3 g/cm³

Temperature :

• 0°C to 100°C

Pressure :

• 0 to 10 bar

Measurement Modes :

• Continuous
• Single
• Multiple

Accuracy :

Density :

• Model A: 0.00005 g/cm³
• Model B: 0.0001 g/cm³
• Model C: 0.00001 g/cm³
• Model D: 0.0002 g/cm³

Temperature :

• Model A: 0.02°C
• Model B: 0.03°C
• Model C: 0.01°C
• Model D: 0.05°C

Repeatability :

Density :

• Model A: 0.000005 g/cm³
• Model B: 0.00005 g/cm³
• Model C: 0.000002 g/cm³
• Model D: 0.00002 g/cm³

Temperature :

• Model A: 0.01°C
• Model B: 0.02°C
• Model C: 0.001°C
• Model D: 0.02°C

Resolution :

Density :

• Model A: 0.00001 g/cm³
• Model B: 0.0001 g/cm³
• Model C: 0.000001 g/cm³
• Model D: 0.0001 g/cm³

Temperature :

• Model A: 0.01°C
• Model B: 0.01°C
• Model C: 0.001°C
• Model D: 0.01°C

Wetted Materials :

• Borosilicate glass
• PTFE and ECTFE

Display :

• 10.4-inch diagonal color flat-panel monitor
• 800 × 600 pixel resolution
• Touchscreen interface with spill protection
• Brightness: 200-bit as specified

Communication Interface :

• Touchscreen user interface
• 5 USB ports
• 2 Ethernet ports
• 1 HDMI port
• 2 RS232 ports
• Keyboard, barcode scanner and mouse connectivity
• Network connectivity

Video and Magnification :

• Video-assisted cell viewing
• Approximately 10X magnification

Internal Memory :

• 32 GB non-removable CompactFlash memory

Sample Loading Options :

Horizontal Loading :

• Suitable for laboratories performing a few measurements per day
• Requires only 1 mL of sample

Vertical Loading :

• Gravity-assisted sample loading
• Allows air bubbles to rise to the top of the syringe
• Suitable for left-handed and right-handed operators
• Provides improved control during syringe operation

LoadAssist :

• Supports manual injection or syringe loading using a peristaltic pump
• Helps maintain consistent sample injection for multiple users

Dimensions (L × W × H) :

• 46 × 28 × 53 cm

Net Weight :

• 24 kg

Standard Accessories :

• Water density standard
• IQ/OQ documentation
• 3 mL syringes with elastomeric-tipped plungers: 6 pieces
• 3 mL Luer slip-tip syringes: 6 pieces
• Waste collection flask
• Silicone hose, 1/8-inch ID × 3/16-inch OD, 6 feet
• Male Luer plugs: 2 pieces
• Hose-barbed male Luer adapters: 4 pieces
• PTFE filling nozzles: 2 pieces
• Female Luer to 1/4-inch-28 thread ETFE adapters: 2 pieces
• Female Luer Lock to 1/4-inch-28 thread ETFE adapters: 2 pieces
• Barbed to 1/4-inch-28 thread UNF ETFE adapters: 2 pieces
• Small Phillips-head screwdriver
• Nozzle repair tool
• Power supply and power cord

Optional Accessories :

• 21 CFR Part 11 compliance option
• Refractometer control module
• Heated interface attachment
• USB barcode scanner
• Digital thermometer with temperature probe and calibration certificate
• USB inkjet printer kit
• USB laser printer kit
• 40-column serial printer kit with communication cable and adapter

• Supports continuous, single and multiple measurement modes
• Horizontal, vertical and assisted sample loading options
• Requires only 1 mL of sample for measurement
• Touchscreen interface for convenient operation
• Video-assisted cell viewing with approximately 10X magnification
• Internal memory for data storage
• Multiple USB, Ethernet, HDMI and RS232 communication ports
• Compatible with a keyboard, mouse and barcode scanner
• Integrated temperature and pressure measurement capabilities
• Designed for reliable and repeatable laboratory measurements
