Automatic Heated Oil Test Centrifuge for Petroleum Testing Equipment

The Fully Automatic Petroleum Testing Centrifuge is designed to determine sediment and water content in crude oil, fuel oils, middle distillate fuels and biodiesel. It is also suitable for evaluating precipitation numbers, demulsibility characteristics, trace sediments and insoluble materials in used lubricating oils. The centrifuge features a touchscreen control panel for setting temperature, test duration, speed and rotor assembly. Its automatic acceleration, speed control and braking functions ensure convenient and consistent operation. The unit accommodates long, short and pear-shaped centrifuge tubes and includes safety interlocks, thermal insulation and an optional nitrogen purge function for petroleum laboratory applications.

Manufactured by Atico Export with a focus on precision, durability and consistent performance in petroleum testing laboratories.

• Determination of sediment and water content in crude oil
• Testing of fuel oils, middle distillate fuels and biodiesel
• Measurement of precipitation numbers in petroleum products
• Evaluation of demulsibility characteristics
• Determination of trace sediments and insolubles in used lubricating oils
• Petroleum quality control and laboratory analysis

Capacity :

• Four oil test centrifuge tubes
• Long tubes: 100 mL
• Short tubes: 100 mL
• Pear-shaped tubes: 100 mL

Maximum Speed :

• 2200 RPM

Maximum Relative Centrifugal Force (RCF) :

• Long tubes: 1327
• Short tubes: 1170
• Pear-shaped tubes: 865

Timer :

• 0 to 999 minutes

Set Speed :

• 200 to 2200 RPM

Speed Readout :

• 0 to 2200 RPM

Temperature Control :

• Ambient to 93°C (200°F)

Temperature Readout :

• Digital

Braking System :

• Automatic dynamic braking

Electrical Requirements :

• 115 V, 60 Hz, 7 A
• 230 V, 50/60 Hz, 3.5 A

Dimensions (L × W × H) :

• 78.74 × 65.53 × 36.32 cm

Net Weight :

• 44.5 kg

Compatible Rotor Assemblies :

• Rotor assembly for long tubes
• Rotor assembly for short tubes
• Rotor assembly for pear-shaped tubes

Compatible Accessories :

• Long centrifuge tubes, 100 mL, with millilitre graduations
• Long centrifuge tubes, 100 mL, with 200-part graduations
• Long centrifuge tubes with fine graduations above 10 mL
• Long centrifuge tubes with 2-part graduations above 20 parts
• Cone-shaped centrifuge tube, 100 mL, with capillary tip
• PTFE cushions for long tubes
• PTFE cushions for long tubes with capillary tips
• Short centrifuge tubes, 100 mL, with millilitre graduations
• Short centrifuge tubes with 200-part graduations
• Short centrifuge tubes with fine graduations above 10 mL
• PTFE cushions for short tubes
• Pear-shaped centrifuge tubes, 100 mL, with millilitre graduations
• Pear-shaped centrifuge tubes with 0.01 mL graduations from 0 to 0.2 mL
• Cork stoppers for long, short and pear-shaped tubes
• Finger centrifuge tubes
• Felt support for finger tubes

• Fully automatic benchtop centrifuge for petroleum testing
• Accommodates four centrifuge tubes of 100 mL capacity
• Compatible with long, short and pear-shaped ASTM centrifuge tubes
• Automatic control of acceleration, centrifugation speed and timing
• 4.5-inch LCD touchscreen control panel
• Adjustable temperature control for heated testing
• Servo-controlled motor speed mechanism
• Automatic calculation of RPM based on selected RCF and rotor type
• Substantial thermal insulation to reduce heat loss
• Precise balancing for quiet operation
• Large, clear, top-opening lid with viewing window
• PTFE cushions for tube protection and positioning
• Safety interlock prevents operation when the lid is open
• Emergency shutdown and door-locking mechanism
• Nitrogen purge facility requiring an external nitrogen supply
• Class 1, Division 2 explosion-resistant rating
