Compressor Training System

The Compressor Training System provides a platform for training in compressor circuit wiring. It includes two start-up methods:

• Current-mode
• PTC

Students can understand the operating principles of the compressor by observing and measuring signals from the circuit terminals.

The system includes an internal refrigeration setup, allowing the start-up circuit to drive a real compressor once correct wiring is completed. Additionally, several meters are integrated into the front panel and connected to the compressor at the back for convenient observation and measurement during operation.
