Jamesson Column Flotation

The Jamesson Column Flotation is an advanced laboratory equipment designed for high-efficiency and precision in ore beneficiation labs.

Dimensions :

• 1000x2100x3600 mm

• Transparent Circular Column Cell : The device features a transparent circular column cell with a diameter of 200 mm and a height of 900 mm, allowing full observation of material behavior throughout the flotation process.

• Pulp Feeding : Equipped with a variable-speed peristaltic pump for precise pulp feeding control.

• Pulp Feed Tank : Includes a 50-liter conical-bottom stainless steel pulp feed tank with an adjustable-speed mechanical stirring system, ensuring homogeneous pulp feeding.

• Wash Water Feed Tank : A 50-liter conical-bottom stainless steel wash water feed tank ensures smooth and efficient water delivery to the system.

• Flow Meters : The device is equipped with flow meters for measuring and controlling water and air flow, allowing precise management of the flotation process.

• Micronized Atomizer Water Spray Nozzles : Features micronized atomizer water spray nozzles for the concentrate washing process, enabling effective cleaning of concentrates.

• Mobile Steel Stand : The entire system is mounted on a mobile steel stand with lockable wheels, allowing easy movement within the laboratory and adaptability to various workspaces.
