The Fine Gold Finishing Shaking Table is a gravity concentration device specifically designed for the final upgrading of gold concentrates to produce a high-grade, directly smeltable product.
It is used as a finishing unit after primary concentration processes and is capable of recovering fine gold from low-grade concentrates with high efficiency. The table operates using a controlled shaking motion combined with water flow to separate particles based on density.
The table operates using:
- Reciprocating motion (shaking)
- Controlled water flow across the deck
Process Flow :
- Feed is supplied at a constant rate
- Water flows across the deck
- Shaking motion causes stratification:
- Heavy gold particles → settle in grooves
- Light particles → washed away
- Concentrated gold is collected for smelting
Key Concept :
- Designed specifically for fine gold finishing and upgrading
- Uses optimized deck grooves for maximum recovery
PERFORMANCE ADVANTAGES :
- Produces directly smeltable gold concentrate
- High recovery even from low-grade feed
- Efficient for fine gold particles
- Simple tuning with minimal adjustments
- Low installation and maintenance requirements
INSTALLATION & OPERATION NOTES :
Installation :
- Can be installed on standard floor
- No special foundation required
- Requires electrical and water connection
Operation Requirements :
- Maintain constant feed rate
- Ensure clean and steady water supply
- Remove iron particles before feeding (recommended)
LIMITATIONS :
- Requires pre-concentrated feed (not for raw ore)
- Performance depends on:
- Feed consistency
- Water pressure stability
- Limited capacity compared to primary concentrators
