Abdominal Organ Chambers for Large Animal Liver or Kidney for Physiology Lab

Abdominal Organ Chambers for Large Animal Liver or Kidney for Physiology Lab Flexible, standard jacketed and fully heated chamber designed for ex vivo perfusion of most abdominal organs from large animal models. Suitable for perfusion studies involving pig liver or pig kidney, including transplantation studies, xenotransplantation studies and pharmacological research using blood or erythrocyte-containing perfusate. The chamber is designed to maintain isolated organs under physiological temperature conditions and supports organ perfusion for periods ranging from a few hours to one day. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

Applications :

• Physiological and pharmacological research involving perfusion of pig liver or kidney with blood or erythrocyte-containing perfusate
• Liver transplantation studies
• Kidney transplantation studies
• Liver xenotransplantation studies
• Kidney xenotransplantation studies

Application Examples :

Pig Liver :

• Pig liver is placed in a moist, thermostated chamber and perfused with blood or erythrocyte-containing perfusate through the portal vein under constant-flow conditions
• A centrifugal pump with gentle action on blood is used to reduce hemolysis
• Constant flow is maintained by an electronic controller when using a pump that does not provide constant flow or pressure
• Chamber dimensions used in the application example: 400 × 300 × 180 mm

Pig Kidney :

• Pig kidney is placed in a smaller moist, thermostated chamber
• The kidney is primarily perfused under constant-pressure conditions
• Renal artery and renal vein are used for cannulation
• Chamber dimensions used in the application example: 260 × 200 × 210 mm

Perfusion System Requirements :

• Centrifugal pump with gentle action on blood to reduce hemolysis
• Electronic controller for constant-flow or constant-pressure operation
• Flow probe and flowmeter for flow measurement
• Pressure transducer and bridge amplifier for perfusion pressure measurement
• Suitable oxygenator with heat exchanger for oxygenating and warming the blood
• Monitoring system for recording experimental parameters
• Recording and evaluation software

Included Components :

• Jacketed plexiglass chamber with connections for perfusion tubes
• Jacketed cover
• Tubing for thermostatic circulation
• Tubing for perfusion

Additional Equipment Required :

• Thermocirculator
• Pump with analog control
• Servo-controlled perfusion system
• Measurement system for flow and pressure
• Oxygenator with heat exchanger
• Monitoring system setup
• Recording and evaluation software

Available Chamber Sizes :

• Medium animal organ perfusion chamber with jacketed top and base; inner chamber dimensions: 270 × 340 × 180 mm
• Large animal organ perfusion chamber with jacketed top and base; inner chamber dimensions: 370 × 340 × 190 mm
• Extra-large animal organ perfusion chamber with jacketed top and base; inner chamber dimensions: 550 × 340 × 210 mm

• Jacketed heated chamber maintains physiological temperature conditions
• Supports constant-flow or constant-pressure perfusion in a single system
• Can be expanded to monitor and record pressure, flow, pH, pO2, pCO2 and temperature
• Compatible with a variety of accessories for a wide range of applications
• Provides a complete perfusion system when combined with a perfusion control system with pressure and flow regulation
