Aerosol Nebulizer for Physiology Lab

Aerosol Nebulizer for Physiology Lab designed for aerosolizing drugs that are sensitive to ultrasonic cavitation and higher temperatures. The system produces low particle sizes without requiring solution warming, while compressed air automatically transports the generated aerosol. All generated particles are 10 µm or less, with approximately 60% of particles measuring 2.5 µm or less. The nebulizer requires compressed air at an operating pressure of approximately 1.5 bar (22 psi). Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

• Aerosol drug delivery studies
• Respiratory research
• Respiratory mechanics applications
• Small-animal aerosol administration
• Nebulization of drugs sensitive to ultrasonic cavitation
• Nebulization of drugs sensitive to higher temperatures

Connection Requirements :

• Connecting block required for attachment to single- or double-chamber plethysmographs
• Connecting block required for attachment to mouse plethysmograph
• Multi-gas inlet adapter required for use with compatible small-animal ventilators
• Multi-gas adapter kit available for chamber or box applications

Compressed Air Requirement :

• Operating pressure: approximately 1.5 bar
• Equivalent pressure: approximately 22 psi

Particle Size :

• 100% of nebulized particles: below 10 µm
• Approximately 60% of particles: 2.5 µm or less

Particle Size Distribution :

• 10.5 µm: 100% nebulized, 0% of total particles in band
• 8.19 µm: 99.7% nebulized, 0.2% of total particles in band
• 6.37 µm: 98.0% nebulized, 1.7% of total particles in band
• 4.97 µm: 92.2% nebulized, 5.8% of total particles in band
• 3.88 µm: 80.9% nebulized, 11.3% of total particles in band
• 3.04 µm: 68.3% nebulized, 12.6% of total particles in band
• 2.40 µm: 61.5% nebulized, 6.8% of total particles in band
• 1.90 µm: 57.7% nebulized, 3.8% of total particles in band
• 1.52 µm: 54.5% nebulized, 3.2% of total particles in band
• 1.22 µm: 52.0% nebulized, 2.5% of total particles in band

Available Configurations :

• Aerosol nebulizer
• Aerosol nebulizer with multi-gas adapter kit and stand for chamber or box applications
• Multi-gas inlet adapter and stand for connection to compatible ventilators
• Aerosol nebulizer connection kit for pressure regulator

Pressure Regulator Connection Kit :

• Operating pressure range: 1.5 to 2 bar
• Equivalent pressure range: 22 to 30 psi
• Quick connector with shut-off
• Pressure tube length: 2 m
• Tube ID: 2 mm
• Tube OD: 3 mm

• Jet nebulizer for temperature-sensitive and cavitation-sensitive drugs
• 100% of nebulized particles below 10 µm with fluids having viscosity similar to saline solution
• Approximately 60% of particles are 2.5 µm or less
• No solution warming required
• Aerosol automatically transported by compressed air
• Operating pressure of approximately 1.5 bar (22 psi)
• Suitable for respiratory mechanics applications
• Available with multi-gas adapter configuration
• Can be used with chamber or box systems
