Analog Bipolar Temperature Controllers For Pharmacology Research Lab Equipment

Description :

Temperature control systems designed for heating and cooling in electrophysiological experiments. The systems provide precise temperature regulation with low-noise operation and protection features to help prevent damage to experimental preparations.

Manufactured by Atico Export with a focus on precision, durability and consistent performance for laboratory applications.

• Electrophysiological experiments
• Heating and cooling control
• Peltier temperature control
• Resistive heating applications

Technical Specifications :

• Single temperature control channel plus thermometer channel
• Two independent temperature control channels
• 19-inch standard rackmount cabinet
• Built-in power supply and cooling
• Digital temperature displays
• Adjustable PI temperature controller
• Adjustable output power control
• Maximum output voltage: approximately 15 V
• Current limit: 5 A
• Short-circuit and electronic protection

Temperature Sensors :

• Semiconductor sensor: 2252 Ω at 25 °C
• Optional PT100 sensor: 100 Ω at 0 °C

Output :

• Bipolar output: ±15 V DC
• Unipolar output: +15 V for heat-only applications
• Suitable for Peltier elements and resistive heating loads
