Automated Tail Suspension Test for Behavioral Research test

The Automated Tail Suspension Test is designed for rapid and reliable screening of the psychotropic properties of pharmacological substances, including antidepressant and sedative effects, in mice. The system evaluates the movements of suspended animals by analyzing the force, energy, and power developed over time. Fully automatic and operator-independent operation allows measurement of up to 6 animals in a single run, with multiple randomization processes available for animal lists and full calibration control. The system provides a short experimental duration, typically around 6 minutes, and allows experiments to be replayed using different analysis parameters. Optional video recording can be used to adjust the activity threshold. Experimental results can be printed or stored in text or spreadsheet-compatible formats, while wireless communication provides additional flexibility. Manufactured by Atico Export with a focus on reliable performance for animal behavioral, phenotyping, and pharmacological research.

• Antidepressant research
• Sedative drug studies
• Psychotropic drug screening
• Behavioral pharmacology
• Phenotyping studies
• Depression-related behavioral research
• Animal behavioral research
• Pharmacological screening

Technical Specifications :
Number of Animals :

• 1–3 mice with one set of cages
• 1–6 mice with two sets of cages

Cage Configuration :

• 3 suspension cages per set
• Up to 6 animals using two cage sets

Material Composition :

• Black and white PVC

Power :

• 110–230 V
• 9 V DC

Dimensions :

• 50 × 15 × 30 cm for a set of three cages

Sensor Acquisition Sampling Rate :

• 200 Hz

Camera Sampling Rate :

• 15 images/second

Data Analysis :

• Force
• Energy
• Power developed over time

Video Option :

• Optional USB video camera with optics and stand

Data Storage Formats :

• TXT
• XLS

PC Requirements :

• Windows 7 / 8
• 32-bit or 64-bit operating system
• Intel Core i3, 2.4 GHz or equivalent
• RAM: 3 GB
• USB 2 / USB 3
• Display resolution: 1152 × 768 pixels
• 1 free USB port per cage set
• 1 additional free USB port for the camera
• Compatible with touchscreen tablet using Windows 8

• Fully automatic and operator-independent operation
• Measures up to 6 mice in the same run
• Up to 4 types of animal-list randomization processes
• Full calibration control
• Analysis based on force, energy, and power developed over time
• Based on innate behavior and despair models
• Short experimental duration, usually approximately 6 minutes
• Simple setup and operation
• Experiments can be replayed using different parameters
• Optional video recording for activity threshold adjustment
• Wireless communication
• User-friendly software for experiment control, recording, analysis, and replay
• Results can be printed or stored in text or spreadsheet-compatible formats
• Suitable for phenotyping and pharmacological studies
