Blood Pressure Transducers for Physiology Lab

The Blood Pressure Transducer is a reliable and accurate pressure transducer designed for measuring arterial blood pressure across different animal species, including small animals with high heart rates. It is suitable for in vivo arterial pressure measurement, perfusion pressure measurement in isolated organs such as the heart or kidney, and isovolumetric left ventricular pressure measurement using a balloon in isolated hearts ranging from mice to larger animals. The transducer features low volume displacement, easy filling, included stopcocks, and a simple holder for rod mounting. It consists of a contact plate with cable and an exchangeable transducer head for convenient replacement. Manufactured by Atico

• In vivo arterial blood pressure measurement
• Perfusion pressure measurement in isolated organs
• Isolated heart perfusion pressure measurement
• Isolated kidney perfusion pressure measurement
• Isovolumetric left ventricular pressure measurement
• Pressure measurement in isolated hearts from small to larger laboratory animals

Operating Pressure :

• -300 to +300 mmHg

Overpressure :

• 4000 mmHg

Sensitivity :

• 5 µV/V/mmHg (±1%)

Temperature Coefficient :

• 0.1%/°C

Zero Drift :

• <0.2 mmHg/°C

Zero Offset :

• <25 mmHg

Excitation Voltage :

• 2 to 15 VDC
• AC up to 5 kHz

Isolation Against Fluid :

• 5,000 V

Operating Temperature :

• 15° to 40°C

Storage Temperature :

• -25° to 70°C

Volume Displacement :

• <0.04 mm³ / 100 mmHg

Output Impedance :

• 365 Ω ±1%

Frequency Response :

• 1 kHz

Cable Length :

• 3 m (9.8 ft)

Certification :

• CE

• Reliable and accurate pressure measurement
• Low volume displacement
• Suitable for arterial pressure applications
• Suitable for high heart-rate animal studies
• Easy to fill
• Stopcocks included
• Simple holder for rod mounting
• Exchangeable transducer head
• Replaceable contact plate with cable
• Available with contact plates and cables for different amplifier configurations
