Centrifugal Pump for Physiology Lab

The Centrifugal Pump is specifically designed for pumping blood and erythrocyte suspension solutions in physiological and pharmacological laboratories. A complete setup consists of a digital pump drive with centrifugal head mounting plate and a centrifugal pump head. The pump head is hermetically sealed and provides flow rates up to 10 L/min, with the achievable flow rate depending on perfusion circuit resistance. A priming circuit and instruction manual are supplied for care and use. The pump can be integrated with pressure measurement, transducer amplification, servo control, and modular housing systems to perform constant pressure perfusion. The robust drive is suitable for continuous speed selection operation. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

• Physiological research
• Pharmacological research
• Blood perfusion
• Erythrocyte suspension circulation
• Perfusion circuit testing
• Constant pressure perfusion
• Experimental cardiovascular and physiological studies

Constant Pressure Perfusion Option :

• Pressure transducer
• Pressure transducer holder
• Lab stand with triangular base plate
• Manual pressure calibrator
• Transducer amplifier module
• Servo controller for perfusion
• Modular amplifier case

Speed Range :

• 36 to 3600 rpm

Flow Rate and Pressure :

• Depending on pump head

Maximum Flow Rate :

• Up to 10 L/min

External Control :

• Analogue interface 0 to 10 V or 0 to 5 V

Power Supply :

• 115 to 230 V, 50/60 Hz

Fuse :

• 1 × 3.15 A T, slow blow

Operating Conditions :

• Laboratory environment
• Temperature: +5 to +40°C
• Relative humidity: 80% maximum

Drive Dimensions :

• 10.5 × 8 × 8 in
• 267 × 203 × 203 mm

Weight :

• 15.5 lb
• 7.0 kg

• Specifically designed for pumping blood and erythrocyte suspension solutions
• Suitable for physiological and pharmacological laboratory applications
• Hermetically sealed pump head
• Flow rates up to 10 L/min
• Robust drive suitable for continuous speed selection operation
• Supplied with a priming circuit
• Suitable for constant pressure perfusion when combined with compatible pressure measurement and control components
• External control through analogue interface
• Wide-range power supply
• Suitable for continuous laboratory operation
• CE conformity
