Compact 5/9 Holes Box for Behavioral Research test

The Compact 5/9 Holes Box is designed for evaluating attention performance in laboratory animals using visual discrimination tasks. The system consists of a test chamber with food or liquid dispensing options, a computer connection interface and software for experiment control and data analysis. It provides up to 9 hole positions, allowing different numbers of holes and varying levels of test difficulty. Each hole is equipped with an infrared photocell beam for detecting nose-poke responses and an internal LED for providing adjustable visual cues. The system supports sustained attention, impulsive behavior and lateralized discrimination studies, including the 5-choice serial reaction time task. The system is manufactured by Atico Export for reliable performance in animal behavioral and cognitive research.

• Attention performance testing
• Visual discrimination tasks
• Sustained attention studies
• 5-choice serial reaction time task (5CSRT)
• Impulsive behavior research
• Lateralized discrimination studies
• Animal learning and cognitive research
• Behavioral pharmacology
• Food and liquid reward-based behavioral experiments

Subject :

• Mouse
• Rat
• Mouse

Cage Dimensions, Internal :

• Mouse: 25 (W) × 28 (D) × 24 (H) cm
• Rat: 25 (W) × 28 (D) × 24 (H) cm
• Mouse: 19 (W) × 22 (D) × 24 (H) cm

Cage Dimensions, External Including Base :

• 44 (W) × 37 (D) × 35 (H) cm

Hole Dimensions :

• Mouse: 13 mm diameter; 14 mm deep; IR beam at 5 mm from entry
• Rat: 23 mm diameter; 14 mm deep; IR beam at 10 mm from entry
• Mouse: 13 mm diameter; 10 mm deep; IR beam at 5 mm from entry

Material Composition :

• Plexiglas
• Aluminium
• Stainless steel

Power Supply :

• 110V/220V, 50/60Hz

Hole Configuration :

• Up to 9 contiguous apertures
• Unused holes can be blocked using metal inserts

Visual Cue System :

• Internal LED provided for each hole
• Adjustable LED intensity

Response Detection :

• Photocell/infrared beam detection
• Nose-poke and receptacle head-entry detection

Reward Options :

• Food pellet dispenser
• Liquid dispenser
• Additional food and liquid dispensing configurations

Computer Connectivity :

• RS232/USB communication
• Up to 8 stations connected to a PC through a single cable

Data Collection :

• Correct responses
• Incorrect responses
• Omissions
• Premature responses
• Perseverance responses
• Time-out responses
• Total receptacle head entries

Software Functions :

• Protocol configuration
• Experiment control
• Experiment running
• Data acquisition
• Data analysis
• 5-choice serial reaction task protocol support

• Up to 9 available holes for flexible experimental protocols
• Different hole positions and numbers of holes can be selected
• Suitable for varying levels of learning difficulty
• Hole LEDs with adjustable intensity
• Infrared beams for detecting nose-poke responses
• Easily removable frontal tray for cleaning
• Modular panel for house light and reward
• Choice of food and liquid dispensers
• Accessory available for running mouse tests in a rat-size box
• Unused holes can be blocked with metal inserts
• Transparent front door
• Food pellet dispenser and pusher for detecting head entries
• Stainless-steel platform
• Up to 8 stations can be connected to a PC through a single cable
• RS232/USB communication
• Protocol assistant for configuring complex 5-choice serial reaction tasks
• Supports automated experiment control and data recording
