Compact Instrument Case for Physiology Lab

The MiniCase Housing is a low-cost, space-saving housing solution for using one or two modular units as conventional stand-alone systems. Unlike larger modular housings supplied as complete ready-to-use systems, the MiniCase does not include a system bus for power supply or signal communication between individual modules. Therefore, MiniCase systems are custom wired and configured according to specific application requirements. The MiniCase is suitable only for selected modules or module combinations. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

Accessories :

• Mains supply cable and operating instructions

Dimensions (H × W × D) :

• 6.3 × 6.3 × 9.8 in
• Option 01: 8.1 in

Dimensions (H × W × D) – Metric :

• 160 × 160 × 250 mm
• Option 01: 206 mm

Housing Construction :

• ABS plastic
• Flame-resistant to UL94VO
• Color: RAL7032 (stone gray)
• Ventilation slots at sides

Module Positions :

• Maximum 4 slot units without extension case
• Up to 6 slot units using internal straps and Option 01 case extension

Power Supply :

• 85 to 264 VAC
• 40 Watts
• Output voltage: +5 VDC, 5 A

Socket Combination :

• 3-pin IEC mains with fuse and mains switch on back of housing

System Configuration :

• No internal system bus for power supply
• No internal signal link between individual modules
• Modules are custom wired according to requirements
• Configuration depends on the selected modules and intended application

• Low-cost housing solution
• Space-saving design
• Suitable for 1 or 2 modules
• Allows modular units to be used as conventional stand-alone systems
• Custom wiring and configuration according to application requirements
• Suitable for selected modules and module combinations
• Can be modified or upgraded to meet specific experimental requirements
