Compact Manual & Automated Radial Mazes for Behavioral Research test

The Compact Manual & Automated Radial Maze is designed for evaluating spatial memory and non-spatial memory in rodents, including memory associated with motivational cues such as food. The eight-arm radial maze consists of a central area with eight sliding doors providing access to eight equally sized arms. The maze is constructed from black Plexiglas and mounted on a tripod with adjustable height. The doors can be operated manually or automatically, allowing flexible experimental control. Animal position can be detected using photoelectric beams or a video-tracking system. Automated operation can be controlled through RS232/USB communication without requiring a PCI interface. Manufactured by Atico Export with a focus on reliable performance for animal behavioral, spatial memory, and cognitive research.

• Spatial memory studies
• Non-spatial memory studies
• Behavioral research
• Cognitive research
• Memory associated with motivational cues
• Food-motivated behavioral experiments
• Rodent learning and memory assessment

Maze Configuration :

• Central area with eight sliding doors
• Eight equally sized arms
• Sliding doors provide access to individual arms
• Black Plexiglas construction
• Adjustable tripod mounting
• Height adjustable up to 1 m
• Arm walls are higher on the proximal side and lower on the distal side
• Arms can be detached by unscrewing the underneath fixing knob
• Detachable recessed cups can be installed at the distal end of each arm
• Covers can replace the recessed cups

Door Operation :

• Manual operation
• Automated operation
• Remote manual control using switches on the control unit
• In-situ manual operation using the provided door-control threads
• Automated door operation based on animal position

Animal Detection :

• Photoelectric beam detection
• Video-tracking system compatibility

Automated Control :

• Automated operation can use photoelectric cells mounted on the maze
• Control through dedicated control unit
• RS232/USB communication
• No PCI interface required

Available Configurations :

• Manual radial maze
• Semi-automated radial maze
• Fully automated radial maze with photoelectric beam detection
• Manual and semi-automated configurations can be used with video-tracking systems
• Automated configuration uses photoelectric detection and dedicated control software

Additional Configuration :

• Water-based radial maze versions are also available for aquatic radial maze studies

• Compact radial maze design
• Eight equally sized arms
• Suitable for spatial memory assessment
• Suitable for non-spatial memory assessment
• Supports standard automated experiments
• Manual or automated door operation
• Animal detection using photoelectric beams
• Compatible with video-tracking systems
• Adjustable tripod height
• Arms are easily detachable
• Detachable recessed cups
• Covers provided for distal arm positions
• RS232/USB communication for automated configurations
• No PCI interface required for automated options
