Compact Shuttle Box for Behavioral Research test

The Compact Shuttle Box is designed for carrying out conditioned reflex experiments, including Active and Passive Avoidance tests, for learning and memory studies in laboratory animals. It consists of two equally sized compartments with independent grid floors, allowing controlled behavioral testing and accurate animal detection through highly sensitive weight transducers. Frontal and top access doors provide convenient access to the experimental area, while different wall shapes and colours can be configured for visual or spatial conditioning. An optional guillotine door allows conversion for Passive Avoidance experiments. The system supports simultaneous control of multiple shuttle boxes through a computer connection without requiring a dedicated PC interface card. A safety system maintains consistent shock intensity regardless of the grid bars contacted by the animal. Manufactured by Atico Export with a focus on reliable performance for animal behavioral and learning research.

• Learning and memory studies
• Conditioned reflex experiments
• Active Avoidance testing
• Passive Avoidance testing
• Animal behavioral research
• Visual and spatial conditioning studies

Animal Detection :

• Highly sensitive weight transducers positioned above the static grids

Compartments :

• Two equally sized compartments

Floor System :

• Two independent grid floors

Access :

• Frontal and top doors

Stimuli :

• General sound generator and visual light stimulus for each compartment

Computer Connection :

• USB or RS-232 connection

Control Capacity :

• Up to 8 shuttle boxes can be controlled simultaneously

Safety System :

• Maintains consistent shock intensity independently of the grid bars contacted by the animal

• Highly sensitive weight transducer system for accurate animal detection
• Two equally sized compartments with independent grid floors
• Easy configuration of different wall shapes and colours
• Optional guillotine door for Passive Avoidance experiments
• Frontal and top doors for easy access inside the box
• General sound generator and visual light stimulus for each compartment
• Supports simultaneous control of multiple boxes from a PC
• USB or RS-232 computer connection
• No dedicated PC interface card required
• Safety system maintains consistent shock intensity independently of the grid bars contacted
• Suitable for Active and Passive Avoidance experiments
