Compact Stereotaxic Instruments for Mouse and Rat for Physiology Lab

The Compact Stereotaxic Instrument for Mouse and Rat allows both mouse and rat adapters and ear bars to be used on a single base unit. The dual-lead screw design provides stable, accurate and smooth manipulation, while laser-engraved scales facilitate easy reading. The instrument provides 180° vertical rotation and 360° horizontal rotation, with the ability to lock at any angle. The base plate measures 40.0 × 25.5 cm. Digital manipulator arms are also available with a displacement transducer and compact LCD display, providing real-time coordinate presentation of all three axes with a resolution of 10 µm. The display can operate using AC power or battery power, reducing electronic noise and making the system suitable for electrophysiology experiments. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

Complete System Includes :

• Base plate
• 3-axis manipulator arm
• Species adapters for mouse and rat
• Ear bars for mouse and rat
• Holder with corner clamp

Digital Manipulator Option :

• Digital manipulator arm with displacement transducer
• Compact LCD display
• Real-time coordinate presentation of all three axes
• Resolution of 10 µm
• AC or battery operation
• Reduced electronic noise
• Suitable for electrophysiology experiments

Base Plate Dimensions :

• 40.0 × 25.5 cm

• Small footprint
• Adapters for rat, mouse, mouse/neonatal rat and additional applications
• Resolution of 100 µm for manual versions
• Resolution of 10 µm for digital versions
• Single or dual manipulator arm
• Manual or digital manipulator options
• Stable, accurate and smooth manipulation
• 180° vertical rotation
• 360° horizontal rotation
• Lockable at any angle
