Einthoven Goldberger and Wilson Lead Amplifier Module Accessories for Physiology Lab

The Einthoven Goldberger and Wilson Lead Amplifier Module Accessories for Physiology Lab are designed for use with Einthoven Goldberger and Wilson Lead Amplifier Modules. Mini ECG electrodes are mounted on an insert designed for multi-lead ECG recording on large hearts such as rabbit hearts. The insert can be mounted on an isolated heart system, and individual electrodes can be adjusted to position them as close as possible to the heart surface. Depending on the number of electrodes installed, the system can be configured to reproduce Einthoven derivations as well as Wilson V1-V6 unipolar leads. The electrodes connect to the input box of the ECG amplifier system. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

• Multi-lead ECG recording
• ECG recording from large hearts
• Rabbit heart ECG studies
• Einthoven lead configuration
• Physiological and electrophysiological research

Electrode Configuration :

• Supports Einthoven derivation
• Supports Wilson V1-V6 unipolar leads
• Number of electrodes can be configured according to the required lead arrangement

Input Box :

• Accepts up to 12-lead ECG
• 10-wire ECG configuration
• Includes connection cables for the ECG amplifier modules

Available Accessories :

• Contact ECG electrode with silver chloride pellet
• ECG electrode insert for 12-lead ECG recording
• Input box for up to 12 ECG channels, without MAP
• Connection cables for ECG amplifier modules

• Mini ECG electrodes mounted on an electrode insert
• Designed for multi-lead ECG recording
• Suitable for large hearts such as rabbit hearts
• Insert can be mounted on an isolated heart system
• Individual electrodes can be adjusted close to the heart surface
• Supports Einthoven derivation configurations
• Supports Wilson V1-V6 unipolar lead configurations
• Input box supports connection of ECG electrodes to amplifier modules
• Input box accepts up to 12-lead ECG with 10-wire configuration
