EMC Shielded Environmental Cabinet for Physiological Research Instrumentation

The EMC Shielded Environmental Cabinet provides an acoustically insulated and electromagnetically controlled environment for electrophysiology, physiological recordings and experimental laboratory applications. Manufactured by Atico Export with attention to applicable quality, safety and functional requirements for physiological research and laboratory applications.

• Provides a controlled environment for sound, light and electromagnetic interference
• Suitable for electrophysiology and physiological recording applications
• Designed for animal handling, observation and experimental laboratory studies

Construction :

• High-density fiberboard construction for superior acoustic insulation
• Corrosion-resistant coated surfaces
• Integrated Faraday cage with metallized lining
• EMC-gasketed door for electromagnetic shielding
• Cable entry panel and ventilation fan included

Acoustic attenuation :

• Sound transmission between chambers is attenuated to approximately 35 dB
• Additional baffles can provide 5 to 10 dB further attenuation
• Baffles also help reduce light ingress through ventilation apertures
• Sound attenuation performance is frequency dependent

Electromagnetic shielding :

• Faraday cage helps attenuate external electromagnetic interference
• Designed to provide a clean electromagnetic environment for physiological recordings
• Requires proper grounding as part of the shielded system
• Shielding performance depends on the frequency and proximity of electromagnetic radiation

Ventilation :

• Panel-mounted ventilation fan with air inlet
• Cable entry points provided
• Ventilation arrangement supports controlled internal conditions

Animal handling :

• Ergonomic design for convenient animal handling and welfare
• Optional rolling shelf simplifies handling, particularly for tethered animals

Observation options :

• White LED house light and speaker
• Spyhole lens for direct observation
• Visible or IR camera system for observation and recording

Easy-install rack system :

• Suitable for mounting multiple chambers
• Moveable rack with braked wheels for convenient handling and laboratory cleanliness
• Central power distribution point with earth bonding
• Cables can be organized through dedicated trunking
• Additional wall fixtures available for taller chambers or increased spacing

Internal dimensions :

• 544 mm W x 410 mm D x 603 mm H

External dimensions :

• 604 mm W x 470 mm D x 663 mm H
