Environmental Cabinet for Physiological Research Instrumentation

The Environmental Cabinet provides a controlled, acoustically insulated environment for physiological research, animal handling, observation and experimental laboratory applications. Manufactured by Atico Export using carefully selected materials and controlled production processes for dependable performance in physiological research and laboratory applications.

• Provides a controlled environment for sound and light during physiological and experimental laboratory studies
• Designed for animal handling, observation and physiological recording applications

Construction :

• High-density fiberboard construction for superior acoustic insulation
• Corrosion-resistant coated surfaces
• Structural design suitable for vertical stacking
• Single-handle door for convenient operation

Acoustic attenuation :

• Reduces sound transmission between cabinets to approximately 35 dB
• Door air seal supports consistent acoustic performance
• Additional baffles can provide 5 to 10 dB further attenuation
• Baffles also help prevent light ingress through ventilation apertures
• Sound attenuation levels are frequency dependent

Ventilation :

• Panel-mounted ventilation fan with air inlet
• Ventilation and cable entry points provided
• Optional dual inflow and exhaust ventilation arrangement

Cable management :

• Cable entry panel with cable glands
• Cable glands maintain the acoustic seal and accommodate different cable sizes
• Cable glands can be positioned as required and securely clamp cables
• Cables can be routed through dedicated trunking in multi-cabinet installations

Internal dimensions :

• 544 mm W x 410 mm D x 603 mm H

External dimensions :

• 604 mm W x 470 mm D x 663 mm H

Optional features :

• White LED house light and speaker
• Visible or IR camera system for observation and recording
• Rolling shelf for simplified animal handling
• Dual inflow and exhaust ventilation
• Faraday cage with metallized lining and EMC-gasketed door for reducing external electromagnetic interference
• Additional wall fixtures for specialized cabinet configurations

Easy-install rack system :

• Suitable for mounting multiple cabinets vertically
• Moveable rack with braked wheels for convenient handling and laboratory cleanliness
• Central power distribution point with earth bonding
• Top shelf for organized electrical connections
• Additional wall-fixture option available for taller cabinets or increased spacing between cabinets
