Forced Exercise Walking Wheel Bed for Physiological Research Instrumentation

The Forced Exercise / Walking Wheel Bed is designed for conducting controlled exercise and sleep deprivation paradigms in mice. The system can accommodate up to 20 individual exercise/walking wheels, with each wheel positioned in its own running track and supported by cushioned non-slip grips. A large removable stainless steel waste pan facilitates cleaning, while the wheels can be added or removed during operation. The system can be placed on rubber feet or permanently mounted to a flat surface or workbench and can be easily disassembled for cleaning. A handheld LCD interface allows setting of exercise/walking speed, exercise time, rest time and number of cycles. A built-in USB interface provides connection to a Windows computer for additional control of scheduled exercise parameters. Manufactured by Atico Export for reliable performance in rodent exercise and behavioral research.

• Forced exercise studies
• Walking exercise paradigms
• Sleep deprivation studies
• Rodent exercise research
• Locomotor activity studies
• Behavioral research

Animal :

• Mouse

Wheel Capacity :

• 1 to 20 wheels

Wheel Configuration :

• Each wheel positioned in an individual running track
• Exercise/walking wheels sold separately

Speed Range :

• 0.9 to 11.4 meters/minute standard
• Adjustable in 0.1 m/min increments

Dimensions :

• 33.9 × 22.25 × 10.875 in (with wheels)

Weight :

• 25.0 lbs. empty
• 41.0 lbs. with 20 wheels

Waste Pan :

• Removable stainless steel construction

Wheel Support :

• Cushioned non-slip grips

Control Interface :

• Handheld LCD interface

Exercise Settings :

• Exercise/walking speed
• Exercise time
• Rest time
• Number of cycles

Computer Connectivity :

• Built-in USB interface
• Compatible with Windows computer-based control and scheduling

Mounting Options :

• Rubber feet
• Permanent mounting to a flat surface or workbench

• Designed for mice
• Supports 1 to 20 exercise/walking wheels
• Each wheel operates in an individual running track
• Cushioned non-slip grips support each wheel
• Large removable stainless steel waste pan
• Wheels can be added or removed while the system is operating
• Rubber feet for stable placement
• Can be permanently mounted to a flat surface or workbench
• Easily disassembled for cleaning
• Handheld LCD interface for exercise control
• Built-in USB computer interface
• Flexible control of scheduled exercise parameters
