Forced Exercise Walking Wheel Bed for Physiological Research Instrumentation

The Forced Exercise / Walking Wheel Bed is designed for conducting controlled exercise and sleep deprivation paradigms in mice. The sturdy exercise bed supports up to 10 individual exercise/walking wheels, with each wheel positioned in its own running track and supported by cushioned non-slip grips. A large removable stainless steel waste pan provides convenient waste collection and cleaning. Wheels can be added or removed while the system is operating. The system can be placed on rubber feet or permanently mounted to a flat surface or workbench and can be easily disassembled for cleaning. A handheld LCD interface allows the user to set exercise/walking speed, exercise time, rest time and number of cycles, while a built-in USB interface allows connection to a Windows computer for flexible control of scheduled exercise parameters. Manufactured by Atico Export for reliable performance in rodent exercise and behavioral research.

• Forced exercise studies
• Walking exercise paradigms
• Sleep deprivation studies
• Rodent exercise research
• Locomotor activity studies
• Behavioral research

Animal :

• Mouse

Wheel Capacity :

• 1 to 10 wheels

Wheel Diameter :

• 5.94 in ID

Wheel Width :

• 2.25 in ID

Run Distance :

• 0.47 meters/revolution

Speed Range :

• 0.9 to 11.4 meters/minute standard
• 0.1 m/min increments

Exercise Time Range :

• 1 minute to 24 hours

Rest Time Range :

• 1 minute to 24 hours

Cycles :

• 1 to 999
• Continuous

Power :

• 15 VDC, 2.0 A power pack included

Line Voltage :

• 110/115 V AC at 60 Hz

Dimensions :

• 19.25 × 22.25 × 10.875 in (with wheels)

Weight :

• 18.7 lbs. empty
• 26.2 lbs. with 10 wheels

Wheel Configuration :

• Exercise/walking wheels sold separately
• Each wheel is independently positioned in its own running track

Control Interface :

• Handheld LCD interface

Exercise Settings :

• Exercise/walking speed
• Exercise time
• Rest time
• Number of cycles

Computer Connectivity :

• Built-in USB interface
• Windows computer connection for scheduled exercise control

Mounting Options :

• Rubber feet
• Permanent mounting to a flat surface or workbench

Waste Pan :

• Removable stainless steel construction

• Supports 1 to 10 exercise/walking wheels
• Each wheel operates in its own running track
• Cushioned non-slip grips support each wheel
• Large removable stainless steel waste pan
• Wheels can be added or removed during operation
• Rubber feet for stable placement
• Can be permanently mounted to a flat surface or workbench
• Easily disassembled for cleaning
• Handheld LCD control interface
• Built-in USB interface
• Flexible control of exercise speed, duration, rest periods and cycles
