Forced Exercise Walking Wheel Bed for Physiological Research Instrumentation

The Forced Exercise / Walking Wheel Bed is designed for rats and provides a flexible platform for conducting controlled exercise and sleep deprivation paradigms. The sturdy exercise bed supports up to 6 individual rat exercise/walking wheels, with each wheel positioned in its own running track and supported by cushioned non-slip grips. Three removable stainless steel waste pans facilitate waste collection and cleaning. Wheels can be added or removed while the system is operating, while rubber feet provide stable placement or the system can be permanently mounted to a flat surface or workbench. The system can be easily disassembled for cleaning. A handheld LCD interface allows setting of exercise/walking speed, exercise time, rest time and number of cycles, while a built-in USB interface provides computer connectivity for flexible control of scheduled exercise parameters. A water support option is also available. Manufactured by Atico Export for reliable performance in rodent exercise and behavioral research.

• Forced exercise studies
• Controlled walking exercise
• Sleep deprivation studies
• Rodent exercise research
• Locomotor activity studies
• Behavioral research

Animal :

• Rat

Wheel Capacity :

• Up to 6 wheels

Total Capacity - Recommended :

• Up to 2.1 kg

Total Capacity - Maximum :

• 3.0 kg

Speed Range :

• 1.0 to 28.0 m/min

Speed Resolution :

• 0.5 m/min

Test Time Range :

• 0 to 24 hours

Rest Time Range :

• 0 to 24 hours

Timing Resolution :

• 1 second

Cycles :

• 1 to 99
• Continuous

Dimensions :

• 51.0 × 17.9 × 16.9 in (with wheels)

Weight :

• 20.0 lbs. empty
• 41.0 lbs. with 6 wheels

Wheel Configuration :

• Each wheel is positioned in an individual running track
• Rat exercise/walking wheels sold separately

Waste Pans :

• Three removable stainless steel waste pans

Control Interface :

• Handheld LCD interface

Exercise Settings :

• Exercise/walking speed
• Exercise time
• Rest time
• Number of cycles

Computer Connectivity :

• Built-in USB interface
• Windows computer connection for scheduled exercise control

Mounting Options :

• Rubber feet
• Permanent mounting to a flat surface or workbench

Water Support :

• Water support option available

• Designed for rats
• Supports 1 to 6 exercise/walking wheels
• Each wheel operates in its own running track
• Cushioned non-slip grips support each wheel
• Three removable stainless steel waste pans
• Wheels can be added or removed during operation
• Rubber feet for stable placement
• Can be permanently mounted to a flat surface or workbench
• Easily disassembled for cleaning
• Handheld LCD control interface
• Built-in USB interface
• Flexible control of exercise speed, duration, rest periods and cycles
• Water support option available
