Hot/Cold Plate Analgesia Meters for Behavioral Research test

The Hot/Cold Plate Analgesia Meter is designed to assess animal sensitivity to pain resulting from exposure to controlled heat or cold stimuli. The system uses a metal plate with electronically controlled heating and cooling, allowing temperature settings to be reached rapidly and maintained with high stability. During testing, the animal is placed on the plate and a built-in timer is started. The timer is stopped when the animal lifts its paw in response to discomfort, providing reaction time as a measure of pain resistance and analgesic efficacy. The system provides a homogeneous temperature surface, front-panel digital temperature display, and convenient foot-switch timing operation. It can also be configured for user-defined temperature ramps and loops, with temperature slope, starting point, and ending point selectable by the user. Data can be transferred to a computer through USB for further analysis. Manufactured by Atico Export with a focus on reliable performance for animal pain, nociception, and analgesia research.

• Analgesia research
• Pain sensitivity studies
• Nociception testing
• Thermal pain threshold assessment
• Hot stimulus response studies
• Cold stimulus response studies
• Analgesic efficacy evaluation
• Animal behavioral and pain research

Temperature Range :

• -2°C to 55°C in a 20–25°C ambient environment at 50% RH

Temperature Accuracy :

• ±0.5°C

Temperature Uniformity on Plate :

• ±0.5°C

Power Requirements :

• 110/220 V automatic
• 100 W

Plate Dimensions :

• 165 × 165 mm

Control Unit Dimensions :

• 305 × 280 × 158 mm

Weight :

• 6.650 kg

Temperature Control :

• Electronic thermostat

Timing Operation :

• Front-panel start/stop switch
• Foot-switch operation

Data Interface :

• USB

Temperature Ramp Function :

• User-defined temperature ramps and loops
• Adjustable temperature slope in °C/min
• User-defined start and end points

• Simple, fast, and accurate operation
• Can be used as a stand-alone instrument
• Supports both hot and cold stimulus testing
• Stable and precise temperature control
• Rapid attainment of preset temperatures
• Homogeneous temperature surface
• Electronic thermostat for temperature regulation
• Front-panel digital thermometer
• Built-in reaction timer
• Practical foot-switch timing operation
• Front-panel start/stop switch
• Temperature ramp and loop functionality
• User-defined temperature slopes, start points, and end points
• USB interface for computer data transfer
• Optional software for defining temperature ramps and storing results
