Hot Plate Analgesia Meter for Behavioral Research test

The Hot Plate Analgesia Meter is designed for rapid and precise screening of analgesic drug properties in small laboratory animals using the hot-plate test. The system uses a 10 mm thick aluminium plate that provides high temperature stability and uniform surface temperature distribution. The plate temperature can be maintained at a selected set point between 45 and 62°C with an accuracy of ±0.1°C using proportional feedback circuits that minimize temperature overshoot. A built-in electronic timer, activated through an external foot switch, enables precise measurement of animal reaction time with 0.1 second precision. The reaction time can be viewed directly on the display or transferred to a computer for further analysis. Manufactured by Atico Export with a focus on reliable performance for animal pain, nociception, and analgesic research.

• Hot-plate analgesia testing
• Analgesic drug screening
• Pain threshold assessment
• Thermal nociception studies
• Animal pain research
• Pharmacological research

Plate Temperature Range :

• 45 to 62°C

Temperature Stability :

• ±0.1°C

Plate Material :

• Aluminium

Plate Thickness :

• 10 mm

Timer Precision :

• 0.1 second

Timer Activation :

• External foot switch

Temperature Control :

• Multiple proportional feedback circuits

Data Recording :

• Trial number
• Plate temperature
• Reaction time

Data Transfer :

• Optional computer-based data transfer and analysis

• Rapid and precise analgesic drug screening
• Digital temperature set point
• High temperature stability
• Uniform temperature distribution across the plate
• 10 mm thick aluminium plate
• Built-in electronic timer
• Foot-switch timing operation
• Hands-free test start and stop
• Temperature control with proportional feedback circuits
• Minimizes temperature overshoot
• Reaction time displayed directly on the instrument
• Optional computer-based data visualization and export
• Suitable for recording trial number, plate temperature, and reaction time
