Instrument Case for Physiology Lab

The basic system case with an internal system bus is supplied completely wired and ready for use. The Type 603 case provides a total space of 20 positions (slot units) The maximum number of modules that can be installed depends on the number of slot units required by each module. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

Accessories :

• Line cable
• Spare fuses
• Screwdriver for fitting function modules
• Document folder for operating instructions of function modules
• 3 × BNC-BNC output lines

Dimensions (H × W × D) :

• 5.2 × 19 × 17.1 in

Dimensions (H × W × D) :

• 132 × 483 × 435 mm

Housing Construction :

• Metallic housing
• Gray plastic coated
• Universal 19-inch case with pivoting feet
• Prepared for rack mounting

Module Positions :

• Maximum 20 slot units

Power Supply :

• 100 to 240 VAC, 50/60 Hz
• Built-in line filter
• 100 W maximum consumption

Additional Power Supply :

• 24 V power supply available for modules that require it

Socket Combination :

• 3-pin mains with fuse and mains switch on back of housing

Weight :

• 14.3 lbs

Weight :

• 6.5 kg

• Internal system bus
• Completely wired and ready for use
• Provides 20 slot units for modular installation
• Supports modules with one or multiple slot-unit widths
• Additional 24 V power supply available for modules that require it
• Maximum module capacity depends on the slot requirements of individual modules
• Universal 19-inch case design
• Prepared for rack mounting
