IR Actimeter for Behavioral Research test

The Compact Infrared (IR) Actimeter is designed for studying spontaneous locomotor activity, rearings, and optional hole-board exploration parameters in rodents. The system uses a two-dimensional square infrared frame with 16 × 16 infrared beams for reliable animal detection and can be configured for general activity, locomotor and stereotyped movements, rearing, or exploratory behavior. Interchangeable frames can be used in open-field or home-cage configurations, while adjustable infrared sensitivity allows adaptation to different animal types such as rats and mice. The system can operate independently through control units or be connected to a computer for data visualization, export, trajectory analysis, and further behavioral assessment. It requires minimal maintenance and lighting conditions and is suitable for behavioral studies, drug screening, and phenotype characterization. Manufactured by Atico Export with a focus on reliable performance for animal behavioral and locomotor activity research.

• Spontaneous locomotor activity studies
• Rearing behavior studies
• Open-field behavioral testing
• Home-cage activity monitoring
• Hole-board exploration studies
• Locomotor and stereotyped movement analysis
• Drug screening
• Phenotype characterization
• Animal behavioral research
• Exploratory behavior assessment

Detection System :

• Infrared photocell system with 16 × 16 beams per frame

Detection Axes :

• Two-dimensional X and Y axes

Sensitivity :

• Up to 15 sensitivity levels

Animal Compatibility :

• Suitable for rats and mice

Frame Sizes :

• 450 × 450 mm
• 250 × 250 mm

Open-Field Arena Options :

• Arena for 1 subject, 440 × 440 mm
• Arena for 1 subject, 210 × 210 mm
• Arena options for 2 subjects with divider

Hole-Board Option :

• Hole-poke base available for 45 × 45 cm frame

Control :

• Independent control units or computer-based control

Data Handling :

• Data visualization and export through optional computer software

Trajectory Analysis :

• Distance
• Speed
• Permanence time in selected zones

Configuration :

• Open-field mode
• Home-cage mode
• General activity
• Locomotor activity
• Stereotyped movements
• Rearing
• Hole-board exploration

• Compact infrared system for animal activity monitoring
• Study of spontaneous locomotor activity and rearings
• Optional hole-board exploration and nose-poke detection
• 16 × 16 infrared beam arrangement for accurate subject detection
• Interchangeable frames for REAR, ACT, and POKING modes
• Suitable for both open-field and home-cage configurations
• Minimum maintenance required
• Minimum lighting conditions required
• Independent control units allow operation without a computer
• Up to 15 sensitivity levels for different animal types
• Can ignore beams obstructed by cage walls, corners, or other objects
• Supports monitoring of one or several animals depending on configuration
• Optional computer-based data visualization and export
• Optional trajectory analysis including distance, speed, and time spent in selected zones
• Suitable for day and night lighting conditions
