Linear Pneumotachometer for Physiology Lab

Linear pneumotachometer designed to convert gas flow through the device into a proportional pressure-difference signal. The special screen design provides a linear signal over a range of flow rates while maintaining minimum dead space. The heated configuration is recommended where condensation of water vapor may occur and requires a heater controller. The heater shell can be removed when heating is not required. The pneumotachometer provides bidirectional gas flow measurement and can be used with differential pressure transducers. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

• Respiratory research
• Measurement of gas flow
• Airway flow measurement
• Measurement of bidirectional respiratory gas flow
• Applications where condensation of water vapor may occur

Specifications :

• Flow range: 0 to 160 L/min
• Dead space: 13.87 mL
• Airway pressure port: Luer side port
• Main port outer diameter: 22 mm
• Main port inner diameter: 15 mm
• Opposite port outer diameter: 15 mm
• Opposite port inner diameter: 13.2 mm
• Flow measurement: Linear and bidirectional
• Pressure measurement: Differential pressure
• Heating: Heated configuration
• Heater controller: Required

Heater Controller :

• Required for operation of the heated pneumotachometer
• Available controllers can heat one or two pneumotachometers
• Heater shell cable connects to the rear panel of the controller

Adapter Options :

• Standard medical taper diameters: 7.5, 10.5, 15 and 22 mm
• Adapter size and style should be selected to match the connected equipment

Included :

• Heated linear pneumotachometer
• Calibration curve

• Special screen design provides a linear signal over a range of flow rates
• Minimum dead space
• Bidirectional measurement for gas flow in either direction
• Designed for use with differential pressure transducers
• Heated configuration helps reduce condensation of water vapor
• Removable heater shell when heating is not required
• Available in multiple flow ranges
• Supplied with calibration curves
• Standard medical taper adapter diameters available in 7.5, 10.5, 15 and 22 mm
• Other connectors are straight
