Lung Weight Measurement Option for Isolated Perfusion Systems for Physiology Lab

The Lung Weight Measurement (Edema Balance) Option can be added to an isolated perfused lung system for mouse, rat, guinea pig, or rabbit lungs. It enables continuous monitoring and measurement of edema formation over time. Raw data is measured as lung weight, while the calculated value represents weight change over time (dW/dT). The system can also be used to assess vascular permeability by calculating the filtration coefficient from weight changes caused by increasing and decreasing perfusion pressure. The measurement system includes a weight measurement transducer integrated into an alternative lung chamber cover. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

Measurement Range :

• ±10 g or ±22 g
• Available system ranges: 0 to 10 g, 0 to 22 g, and 0 to 80 g

Resolution :

• 20 mg

Displacement :

• 23 m/gm

Compatible Lung Systems :

• IPL-2
• IPL-4

Compatible Animals :

• Mouse
• Rat
• Guinea Pig
• Rabbit

System Components :

• Edema Balance Module with Sensor
• Weight Measurement System
• HSE Weight Measurement Transducer integrated into an alternative lung chamber cover

Available Configurations :

• 0 to 22 g for rat or guinea pig lungs
• 0 to 10 g for mouse lungs
• 0 to 80 g for rabbit lungs

Additional Requirement :

• Edema Balance Module with Sensor is required separately

• Continuous monitoring of edema formation
• Lung weight measurement
• Assessment of vascular permeability
• Calculation of filtration coefficient
• Isolated perfused lung studies
• Mouse, rat, guinea pig, and rabbit lung experiments

• Continuously monitors and measures edema formation over time
• Provides raw lung weight data
• Calculates weight change over time (dW/dT)
• Supports assessment of vascular permeability
• Filtration coefficient can be derived from weight changes induced by increasing and decreasing perfusion pressure
• Measures changes of less than 20 mg
• Weight measurement transducer integrated into an alternative lung chamber cover
• Suitable for isolated perfused lung systems
