Manual Foot Misplacement Corridor for Behavioral Research test

The Manual Foot Misplacement Corridor is designed for assessing motor coordination and balance (gait control) in small laboratory animals such as rats and mice. The apparatus consists of a narrow corridor with transparent Perspex side walls and open extremities connected to plastic home cages. The floor is formed by removable metal bars, allowing the animal to walk across the corridor similarly to walking on a horizontal ladder. This arrangement enables separate observation of front and hind foot placement and accurate counting of foot misplacements. The bar spacing can be adjusted to increase test difficulty and minimize the ability of animals to compensate through learning. The corridor width can also be adjusted according to animal size to prevent turning around. The system can be combined with video tracking for recording and evaluating animal trajectory, displacement, and speed. Manufactured by Atico Export with a focus on reliable performance for animal behavioral and motor coordination research.

• Motor coordination studies
• Balance assessment
• Gait control studies
• Foot placement analysis
• Movement capacity assessment
• Detection of subtle motor impairments
• Behavioral research in rats and mice
• Video-based movement analysis

• The animal is placed at one end of the corridor.
• The animal walks across the removable metal bars similar to walking on a horizontal ladder.
• Front and hind foot placement can be observed separately.
• The total number of foot misplacements is recorded.
• Bar spacing can be changed to increase test difficulty.
• Video tracking can be used to evaluate trajectory, displacement, and speed.

Corridor Length :

• 100 cm

Corridor Height :

• 20 cm

Corridor Material :

• Transparent Perspex

Bar Length :

• 13 cm

Bar Diameter :

• 0.3 cm

Bar Material :

• Metal

• Designed for motor coordination and balance assessment
• Suitable for rats and mice
• Narrow corridor design
• Adjustable corridor width
• Adjustable spacing between bars
• Removable metal bars
• Transparent Perspex side walls
• Separate assessment of front and hind foot placement
• Accurate counting of foot misplacements
• Adjustable difficulty level
• Helps minimize behavioral compensation through learning
• Open corridor extremities for connection to home cages
• Compatible with video tracking systems
• Suitable for trajectory, displacement, and speed assessment
• High sensitivity for detecting subtle loss of movement capacity
