Moist Chamber for Physiology Lab

The Moist Chamber is a flexible, standard jacketed and fully heated chamber designed for ex vivo perfusion of abdominal organs from typical rodent models. This temperature-controlled chamber with a metal tube heat exchanger is intended for perfusion of isolated organs such as kidney, liver, pancreas or mesenteric bed from mice, rats or guinea pigs under controlled physiological temperature conditions. Organ perfusion for a few hours to one day is possible. For long-term perfusion studies, a fully airtight autoclavable moist chamber is recommended. The chamber can be used for constant pressure or constant flow perfusion. Manufactured by Atico Export with a focus on precision, durability and consistent performance for physiological research and experimental laboratory use.

• Rodent isolated organ perfusion
• Liver perfusion
• Kidney perfusion
• Pancreas perfusion
• Mesenteric bed perfusion
• Investigation of small blood vessel tone under the effect of vasoactive substances
• Biochemical studies of metabolic processes
• Drug studies
• Testing of vasodilative drugs
• Testing of drug side effects
• Transplantation studies
• Studies on preservation solutions

Special Application – Rat Mesenteric Bed :

• Moist chamber serves as the key component of the perfusion system
• Mesenteric tissue is placed on a stainless steel mesh
• Stainless steel mesh replaces the silicone plate
• Mesh also acts as an anode during electrical stimulation

Working System Requirements :

• Thermostated circulation water bath with approximately 3 to 5 L capacity
• Distilled water and suitable algal growth inhibitor
• Carbogen source for aeration
• Central carbogen supply or carbogen cylinder with pressure-reducing valve
• Perfusate reservoir
• Gas frit for aeration, where required
• Bubble trap positioned directly before the perfused organ
• Pump, usually a roller pump, with the required output
• Adapted cannula set according to the perfused organ and its size

Recommended Measurement Components :

• Pressure transducer for measuring perfusion pressure
• Bridge amplifier for signal amplification and connection to a PC-based recording system
• Additional measurement of perfusion flow, pH, pCO2 and temperature according to the experimental application

Included Components :

• Jacketed moist chamber with metal tube heat exchanger
• Jacketed cover
• Silicone plate
• Two mini-holder arms for holding and fixing perfusion cannulae

Additional Equipment Required :

• Thermocirculator
• Bubble trap
• Cannulae
• Holders
• Peristaltic pump
• Transducers
• Monitoring system setup
• Data recording and evaluation software
• For constant pressure perfusion, a pressure controller, transducer amplifier modules and housing are required in addition to the peristaltic pump

Chamber Dimensions :

• Organ chamber: 110 × 40 × 35 mm

Operation & Setup :

• Consists of a suitably deep organ chamber and cover
• Chamber and cover are double-walled and water-jacketed
• Provides a stable, temperature-controlled environment
• Perfusate is warmed through the built-in heat exchanger
• Bubble trap should be positioned in the perfusate path immediately before contact with the organ
• Flexible silicone platform provides a resting surface for organ fixation
• Fixing pins can be used when required
• Anchors for positioning components are pre-drilled on both sides of the organ
• Precision arterial and venous cannulae can be positioned within the chamber
• Multiple measurement and sample ports provide access to the inner chamber
• Allows collection of a wide range of physiological data
• Can be used as part of a constant-flow perfusion system
• A water-jacketed buffer reservoir, peristaltic pump and appropriate cannulae can be used to complete the perfusion circuit
• Thermocirculator maintains the temperature-controlled circuit
• Can also be used with a perfusion control system for constant-pressure perfusion

• Superior temperature control of perfusate and organ
• Precise positioning of cannulae and measurement probes
• Compact and easy to use
• Compatible with a variety of accessories
• Suitable for a wide range of applications
• Can provide a complete perfusion system when combined with a perfusion system or pressure and flow control system
