Monkey CANTAB Intellistation with Liquid Reward for Physiological Research Instrumentation

The Monkey Cognitive Test Intellistation with Liquid Reward is designed for controlled cognitive and behavioral research involving non-human primates. It combines an infrared touch-screen interface, response lever, calibrated liquid reward system and integrated computing hardware within a robust stainless-steel enclosure. Manufactured by Atico Export with attention to precision, durability and consistent performance for physiological research, experimental studies and scientific laboratory applications.

• Test station for computerized cognitive testing of non-human primates
• Designed for stimulus presentation and controlled animal response testing
• Suitable for single-station or multi-station laboratory configurations

System operation :

• Integrated 1.5 GHz CPU or better within each test station
• Can operate independently with an optional keyboard, monitor and mouse
• Multiple test stations can be connected through standard Ethernet for remote operation
• Suitable for connection to a dedicated laboratory network or existing network

Touch screen system :

• 14.875 in (37.78 cm) diagonal response area
• Toughened, splash-resistant infrared touch screen with LCD monitor
• Touch screen enclosed within a heavy-duty metal frame

Response system :

• Fixed response lever
• Calibrated peristaltic pump
• Liquid reward receptacle
• House and signal light
• Reward tray

Liquid reward system :

• Peristaltic pump-based liquid reward delivery
• Flow rate: 12.2 ml/min
• Optional lick tubes can be added when both pellet and liquid reward are required

Construction :

• Robust stainless-steel enclosure
• Hinged stainless-steel side panels with secure latches
• Side panels prevent animals from accessing the feeder and internal components

Dimensions :

• 22 in W x 15 in H x 12 in D
• 56 x 38 x 30 cm

Weight :

• Approximately 50 lbs (22.5 kg)

Electrical requirements :

• Line voltage: 115/230 VAC
• Frequency: 60/50 Hz
• 230 VAC, 50 Hz configuration available with country-specific power cord
