Mouse Activity Wheel for Physiological Research Instrumentation

The Mouse Activity Wheel is a complete mouse living chamber with a voluntary running wheel designed for long-term activity monitoring studies. It is suitable for applications including circadian rhythm research, cardiovascular and pulmonary pharmacology, general activity studies and other behavioral research. The chamber provides food and water support with free access to the activity wheel. It features a clear polycarbonate cage, stainless steel components and a lightweight anodized aluminum wheel designed for easy cleaning and maintenance. The wheel operates with very low friction, while the removable sensor/counter allows convenient maintenance and complete chamber cleaning. The complete chamber can be easily disassembled for cleaning. Manufactured by Atico Export for reliable performance in long-term rodent activity and behavioral research.

• Voluntary running activity studies
• Circadian rhythm research
• Cardiovascular pharmacology
• Pulmonary pharmacology
• General activity monitoring
• Long-term rodent behavioral studies
• Locomotor activity research

Animal :

• Mouse

Cage Dimensions :

• 9.3 × 13.9 × 7.7 in
• Clear polycarbonate cage

Overall Dimensions :

• 13.9 L × 9.25 W × 7.875 H in
• Approximately 35.3 × 23.5 × 20 cm

Weight :

• 5.8 lbs.

Wheel Diameter :

• 5.0 in ID
• 12.7 cm

Run Distance :

• 0.40 meters/revolution

Wheel Drag :

• < 3 grams

Wheel Construction :

• Lightweight anodized aluminum
• Removable design
• Runs on two low-friction bearings

Run Surface :

• 38 rods
• Rod diameter: 0.188 in
• Rod spacing: 0.4298 in centers
• Gap: 0.2418 in
• Approx. 4.8 mm rod diameter
• Approx. 10.9 mm rod spacing
• Approx. 6.14 mm gap

Run Surface Width :

• 2.25 in (5.72 cm) inside

Cage Material :

• Clear polycarbonate

Top Cover :

• Stainless steel
• Flush-fitting design

Access Hatch :

• Removable stainless steel vented hatch

Feeder :

• Attached to top cover
• Sighting slot for viewing feed level
• Optional hopper bracket available

Water Support :

• Water bottle attached to top cover

Sensor/Counter :

• Plug-in sensor/counter
• Removable for maintenance and chamber cleaning

System Maintenance :

• Complete chamber can be easily disassembled for cleaning
• Wheel is removable for cleaning and maintenance

Additional Components :

• Counters, interface and software are ordered separately

• Designed for mice
• Complete living chamber with voluntary activity wheel
• Suitable for long-term activity studies
• Supports circadian rhythm research
• Suitable for cardiovascular and pulmonary pharmacology studies
• Suitable for general activity studies
• Provides food and water support
• Free access to the activity wheel
• Clear polycarbonate cage
• Stainless steel construction
• Lightweight anodized aluminum wheel
• Removable wheel for easy cleaning and maintenance
• Low-friction wheel operation
• Removable stainless steel vented access hatch
• Components secured to the top cover for convenient removal
• Feeder and water bottle attached to the top cover
• Feeder includes a sighting slot for viewing feed level
• Complete chamber can be disassembled for cleaning
