Mouse Activity Wheel with Dual Lickometer for Physiological Research Instrumentation

The Mouse Activity Wheel with Dual Lickometer is designed for long-term circadian rhythm and general activity studies in mice. The chamber incorporates a stainless steel floor at the end of the enclosure to accommodate two 50 ml bottles with sipper tubes for monitoring drinking activity. A separate food hopper is mounted on a hanging bracket, allowing it to be easily removed when not required. The bottles can be removed without disconnecting the wiring, while cover plates allow the system to be configured for studies requiring fewer than two drinking tubes. Standard bedding may be placed in the portion of the tub containing the wheel and food hopper when present. Manufactured by Atico Export for reliable performance in mouse activity, circadian rhythm, drinking and behavioral research.

Overall Dimensions :

• 13.9 × 9.25 × 7.875 in
• 35.3 × 23.5 × 20 cm

Weight :

• 5.8 lbs

Wheel Diameter :

• 5.0 in ID (12.7 cm)

Run Distance :

• 0.40 meters/revolution

Wheel Drag :

• Less than 3 grams

Run Surface :

• 38 rods
• Rod diameter: 0.188 in
• Rod spacing: 0.4298 in centers
• Gap: 0.2418 in
• Approximate rod diameter: 4.8 mm
• Approximate rod spacing: 10.9 mm centers
• Approximate gap: 6.14 mm
• Internal width: 2.25 in (5.72 cm)

Water Bottles :

• Two 50 ml bottles
• Sipper tubes included

Lickometer Configuration :

• Dual lickometer arrangement

Food Hopper :

• Separate removable food hopper
• Hanging bracket mounted

Bottle Removal :

• Bottles can be removed without disconnecting wires

Cover Plates :

• Included for configurations requiring fewer than two tubes

Bedding :

• Standard bedding may be placed in the tub section containing the wheel and food hopper when present
