Mouse Misstep Wheel with Filter Lid for Physiological Research Instrumentation

The Mouse Misstep Wheel with Filter Lid is designed for mouse activity and motor skill studies where a microbiological barrier filter is required. The system combines a configurable activity wheel with a clear polycarbonate living chamber, food and water support, and free access to the activity wheel. Each of the 38 wheel rungs can be individually removed to create different rung patterns and complex running configurations. The removable lightweight anodized aluminum wheel operates with very low friction and can be easily cleaned and maintained. A removable stainless steel vented access hatch provides convenient animal access, while the complete chamber can be disassembled for cleaning. The system is manufactured by Atico Export for reliable performance in rodent activity, motor skill and behavioral research.

Animal :

• Mouse

Cage Dimensions :

• 9.3 × 13.9 × 7.7 in
• Clear polycarbonate cage

Overall Dimensions :

• 13.9 L × 9.25 W × 7.875 H in
• Approximately 35.3 × 23.5 × 20 cm

Weight :

• 5.8 lbs.

Wheel Diameter :

• 5.0 in ID
• 12.7 cm

Run Distance :

• 0.40 meters/revolution

Wheel Rung Configuration :

• 38 removable rungs
• Individual rungs can be removed to create different patterns

Standard Run Surface :

• 38 rods
• Rod diameter: 0.188 in
• Rod spacing: 0.4298 in centers
• Gap: 0.2418 in
• Approx. 4.8 mm rod diameter
• Approx. 10.9 mm rod spacing
• Approx. 6.14 mm gap

Run Surface Width :

• 2.25 in (5.72 cm) inside

Wheel Construction :

• Lightweight anodized aluminum
• Removable design
• Low-friction operation
• Designed for easy cleaning and maintenance

Top Cover :

• Stainless steel
• Flush-fitting design

Feeder :

• Attached to the top cover
• Sighting slot for viewing feed level

Water Support :

• Water bottle support attached to the top cover

Access Hatch :

• Removable stainless steel vented hatch

Wheel Configuration :

• Standard 38-rung wheel
• Configurable motor-skill wheel

Sensor/Counter :

• Plug-in sensor/counter
• Removable for maintenance and chamber cleaning

Cleaning & Maintenance :

• Wheel is removable
• Complete chamber can be disassembled for cleaning
