Mouse Modular Test Chamber for Physiological Research Instrumentation

The Mouse Modular Test Chamber is a compact operant conditioning chamber designed for behavioral studies and training in mice. Its modular construction supports a wide range of stimulus, response and reward configurations, while the removable top, smooth pan rails and accessible components facilitate cleaning and experimental setup. Manufactured by Atico Export with attention to applicable quality, safety and functional requirements for physiological research and laboratory applications.

• Designed for operant conditioning and behavioral studies in mice
• Suitable for basic operant studies, drug discrimination and other behavioral applications
• Reduced floor area facilitates training mice on operant tasks
• Can be used with ABET interface and programming systems or compatible 24–28 V DC control systems

Materials :

• Grid rods and pan: Stainless steel
• Door, back and top: Polycarbonate
• Channel supports: Clear PVC and stainless steel
• Filler panels: Anodized aluminum
• Base: Easily cleaned 3/8 inch (9.53 mm) matte-textured non-toxic polymer

Dimensions :

Overall :

• Length: 19.25 inch (48.0 cm)
• Depth: 10.61 inch (26.95 cm)
• Height: 10.5 inch (27.67 cm)

Animal Workspace :

• Length: 7.375 inch (18.7 cm)
• Depth: 8.125 inch (20.3 cm)
• Height: 7.9 inch (20.64 cm)

• Easily removable top with four large thumbscrews
• Large stainless steel waste pan for easy removal
• Smooth pan rails eliminate gaps between the pan and modular panels
• Easy-to-clean test environment
• Non-twisting channel supports for no-bind module removal
• Stainless steel grid rod floor supplied as standard
• Optional non-shock perforated stainless steel floor
• Modular options include nose pokes
• Simple tone, tone with intensity control and variable frequency tone
• Stimulus light with or without intensity control
• Standard or retractable response levers
• Pellet or liquid reward
• Receptacle with door
• Head entry detection
• Light module
• Chamber accessories, control system and power supply can be ordered separately
