Narrow Gap Activity Wheel for Physiological Research Instrumentation

The Narrow Gap Activity Wheel is designed for running rats or mice while supporting animal well-being and convenient maintenance. The wheel features a removable sensor/counter that can be detached without tools and does not require special alignment. Its narrow gap design reduces the space between the wheel rim and wheel support to 1/4 inch (6.35 mm) or less, helping prevent mouse escape or injury while allowing mice to be used in a large 14-inch diameter wheel. The system can also be used with rats, with the same core wheel specifications. Manufactured by Atico Export for reliable performance in rodent activity and behavioral research.

Animal Compatibility :

• Rats
• Mice

Wheel Diameter :

• 14 in (35.56 cm) ID

Internal Width :

• 4.3 in (10.922 cm)

Run Distance :

• 1.10 m/revolution

Run Surface Rod Diameter :

• 0.0625 in (1.5875 mm)

Run Surface Rod Spacing :

• 0.3125 in (7.9375 mm) centers

Run Surface Gap :

• 0.25 in (6.35 mm)

Wheel Weight :

• 1.75 lbs (793 grams)

Turning Resistance :

• Less than 6 g

Overall Dimensions :

• 15.63 × 16.18 × 5.719 in
• 41.09 × 39.70 × 14.52 cm

Overall Weight :

• 9.0 lbs (4.08 kg)

Sensor/Counter :

• Easily removable without tools
• No special alignment required

Recommended Counter :

• Activity counter suitable for use with the wheel for both mice and rats
